Specifications
Micro Structure :
Acicular Martensitic + Carbide + Residual Austenite < 6%
Material :
High Chrome
Material Grade :
ASTM A532, AS2027, GX260Cr27, BTMCr25
Place of Origin :
Jiangsu, China
Dimensions :
As per Drawing
Production Process :
Sand Cast
Hardness :
More Than HRC60
Impact Value :
About 5J
Brand Name :
EB
Model Number :
EB11049
MOQ :
60
Application :
Machinery Parts
Description

Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049

Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049

Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049

Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049

1.Material:High Chrome

2.Material Grade:ASTM A532, AS2027, GX260Cr27, BTMCr25
3.Dimensions:as per drawings

4.Special Features:

4-1.Hardness: macro hardness HRC57 - 65, carbide hardness HV1400 -- 1800

4-2.Wear resistance: it is 20, 25 times of low carbon steel, 8, 12 times of stainless steel, high manganese steel, it is general high carbon high chromium wear-resisting steel plate 1.5 times above

4-3.High temperature resistance: general type < 600℃;High temperature < 1000℃.

4-4.Impact resistance: the wear resistant alloy layer and the substrate are fully metallurgy combined, strong impact resistance, no need to worry about falling off machinability: welding, cutting, crimping, drilling

4-5.Connectivity:

4-5-1. Welding, can be assembled and welded into various structural parts or parts through the welding of matrix steel plate

4-5-2. Mechanical connection: plasma cutting gun is used to punch holes in the wear-resistant composite steel plate, and bolts are fixed on the protected equipment to facilitate maintenance and replacement.

5. Chemical Composition:

Reference Standard
(ISO 21988-2005)		Nominal Chemical Composition (W%)Eqv. Standards
CSiMnNiCrMoCuPS
ISO 21988/JN/
HBW555XCr13		1.8-3.6≤1.00.5-1.5≤2.011.0-14.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr11)
ASTM A532 12% Cr
ISO 21988/JN/
HBW555XCr16		1.8-3.6≤1.00.5-1.5≤2.014.0-18.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr14)
ASTM A532 15% Cr-Mo
AS 2027 CrMo 15 3
G-X 300 CrMoNi 15 2 1
ISO 21988/JN/
HBW555XCr21		1.8-3.6≤1.00.5-1.5≤2.018.0-23.00≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr18)
ASTM A532 20% Cr-Mo
AS 2027 CrMo 20 1
G-X 260 CrMoNi 20 2 1
ISO 21988/JN/
HBW555XCr27		1.8-3.6≤1.00.5-2.0≤2.023.0-30.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr23)
ASTM A532 25% Cr-Mo
AS 2027 Cr27 LC & Cr27 HC
G-X 260 Cr27
ISO 21988/JN/
HBW600XCr35		3.0-5.5≤1.01.0-3.0≤1.030.0-40.0≤1.5≤1.2≤0.06≤0.06AS 2027 Cr35
ISO 21988/JN/
HBW600XCr20Mo2Cu		2.6-2.9≤1.0≤1.0≤1.018.0-21.01.4-2.00.8-1.2≤0.06≤0.06AS 2027 CrMoCu 20 2 1

Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049 Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049Cast Iron Foundry ASTM A532 12%Cr High Chrome Cast Iron Block Castings EB11049

Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5~10 days if the goods are in stock.Or it is 45 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment. irrevocable LC at sight.
