Specifications
Place of Origin :
China
Pipe Material :
Copper
certificates :
Solar Keymark SRCC CE CCC ISO
Product name :
Solar Swimming Pool Heater
Material :
3.3 High Borosilicate Glass
Temperature Resistant :
20degrees -115degrees
Tube :
58*1800mm Copper Heat Pipe Tube
Function :
Solar Wate Heater
Color :
Silver
Working pressure :
0.6-0.8Mpa
Collector type :
Glass Metal Heat Pipe Tube
Certificate :
CE
MOQ :
2 sets
Price :
$380-400 / set
Description

Heat Pipe Solar Collectors

Heat pipe solar Collectors Characteristic

1. Adopts red copper channel, with great performance of heat exchange.

2. Utilize copper heat pipes containing special medium liquid with low boiling point.

3. Work well in all climate, can be function well even in ambient temperature of minus 30 degree

Celsius.

4. Each heat pipe tube works independent and efficiently.

5. No water flows inside the vacuum tube, no risk of freezing.

6. Withstand high water pressure of up to 1.2 Mpa.

Heat pipe solar collectors Material

1. Manifold: Aluminum alloy

2. Channel: Red copper

3. Heat pipe: Copper

4. Bracket: Aluminum alloy/ Galvanized steel/ Stainless steel

5. Insulation material: Rock wool

Heat pipe solar collectors data

HEAT PIPE SOLAR COLLECTOR TECHNICAL DATA
MANIFOLD
Manifold casing material Anodized aluminum alloy
Manifold header pipe TU2 copper
Insulation layer Compressed rock wool.
VACUUM TUBES
Tube structure All-glass double deck co-axial structure
Glass material High borosilicate 3.3 glass
Outer tube dia. & thickness Ø58±0.7mm; Glass thickness 1.6±0.15mm
Inner tube dia.& thickness Ø47±0.7mm; Glass thickness 1.6±0.15mm
Tube size 58*1800mm
Absorptive coating property Structure AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN
Sediment method Single target or Three targets - magnetron sputtering plating
Specific absorption 0.90-0.93(AM1.5) / 0.93-0.96(AM1.5)
Emission ratio 0.05-0.075(800C±50C) / 0.04-0.06(800C±50C)
Solar irradiation for obtaining a preset water temperature Φ=58 H≤4.7MJ/m² H=4.1-4.4MJ/m² / H=3.7-4.2MJ/m²
Vacuum tightness 5.0×10¯³ Pa
Idle sunning property parameters 220-260 m².C/KW / 260-300 m².C/KW
Average heat loss coefficient ULT=0.6~0.7W/(M2.0C) / ULT=0.4~0.6W/(M2.0C)
Resistant Hail ≤25mm
Useful life 15 years
HEAT PIPES:
Heat pipe material Oxygen free copper (TU1),Cu=Ag>99.99%(o2<16ppm)
Heat pipe condenser Top: Dia.14mm/ 20mm/22mm/ 24mm, Body: Dia.8mm
Nickel-plated heat pipe (14mm,20mm,22mm, 24mm) optional, will quote per request
Max.working temp -30 ~250C
ΔT 35C(Radiation>=800w/m2.day)
Start-up Temperature <=30C
Resistant Hail ≤25mm
Useful life 15 years
BRACKET
Bracket: Stronger galvanized steel / Stainless steel/aluminium alloy
Bracket angle: 0,18,22,38,45 optional, pitched roof, flat roof optional.
Fastening pieces: Made of zinc-coated stainless steel..
MODEL No. Tube Size Tube No. Aperature Area Gross Area Volume Gross Weight Load Qty 20GP/40HQ
Dia.*L ( m2 ) ( m2 ) ( m3 ) ( kg ) ( sets )
JXSC-58-10 58x1800mm 10 0.94 1.6 0.15 35 186/452
JXSC-58-12 58x1800mm 12 1.22 1.852 0.18 42.8 155/372
JXSC-58-15 58x1800mm 15 1.49 2.315 0.23 52 122/292
JXSC-58-18 58x1800mm 18 1.67 2.778 0.27 62.5 103/245
JXSC-58-20 58x1800mm 20 1.88 3.087 0.29 69.3 96/232
JXSC-58-24 58x1800mm 24 2.23 3.704 0.34 85.3 82/198
JXSC-58-30 58x1800mm 30 2.82 4.63 0.42 104 66/160
