Specifications
Brand Name :
OEM
Model Number :
See details
Place of Origin :
Hubei, China
Cell size :
182mmx182mm, 182mm*182mm
Type :
Half Cell
Panel Dimensions :
2278 * 1134 * 35mm(89.69*44.65*1.38in)
Panel Efficiency :
21.3%, 21.3%
Application :
Solar Panel System
Product name :
Sola Panel
Certificate :
CE,TUV,CQC, CE,CQC,TUV
Warranty :
25 Years, 30 year
Solar cell :
144 Cells
OEM Order :
Acceptable
Color :
Customized Color
Packing :
Wooden Case
MOQ :
100 watts
Price :
$0.19-0.28 / watt
Description
Products Description
Electrical Characteristic
Rated output (Pmp/Wp)
520W
525W
530W
535W
540W
545W
550W
555W
560W
Open Circuit Voltage(Voc)
48.9
49.05
49.20
49.35
49.50
49.65
49.90
50.05
50.20
Short Circuit Current(Isc)
13.57
13.65
13.71
13.78
13.85
13.92
14.00
14.07
14.14
Maximum Power Voltage(Vmpp)
41.05
41.20
41.35
41.50
41.65
41.80
41.96
42.12
42.28
Maximum Power Current(Impp)
12.67
12.79
12.82
12.90
12.97
13.04
13.11
13.18
13.25
Module efficiency(%)
20.3%
20.5%
20.7%
20.9%
21.1%
21.3%
21.5%
21.7%
21.9%
Standard Test Condition(STC)
Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5
Mechanical Characteristic
No.of Cells
144(6x24)
Weight
32.3kg
Dimension
2256x1133x35mm
Junction Box
IP68,three diodes
Output Cables
4mm2,positive 400mm /negative 200mm ,length can be customized
Glass
Dual glass,3.2mm coated tempered glass
Frame
Anodized aluminum alloy frame
