Product Overview
New Electric Power ATS dual power low voltage switchgear is designed for automatic transfer between two independent power sources, providing reliable backup power for critical low-voltage loads. The cabinet integrates an Automatic Transfer Switch (ATS), circuit protection, busbar system, metering and control components in a compact low-voltage distribution enclosure. It can be customized according to local grid conditions, load capacity, cable entry and protection requirements.

Key Product Advantages

• Automatic or manual transfer between utility and standby generator, or between two utility feeders.
• Fast power-source switching helps maintain continuous power supply to critical loads.
• Integrated MCCB/ACB protection, copper busbars, metering and control components.
• Modular cabinet design supports flexible incoming and outgoing feeder configurations.
• Suitable for 3-phase 4-wire or 3-phase 5-wire low-voltage distribution systems.
• Optional electrical/mechanical interlocking prevents two power sources from being connected simultaneously.
• Designed for high-temperature, humid and demanding environments with suitable enclosure and anti-condensation options.
• OEM/ODM customization available for voltage, current rating, cabinet dimensions, protection devices and control functions.
•


Typical Applications in Southeast Asia & Africa
Suitable for commercial buildings, factories, industrial parks, hospitals, schools, hotels, shopping centers, telecommunications facilities, data rooms, water treatment plants, agricultural facilities and infrastructure projects. Common applications include utility + generator backup power and dual-grid power supply systems in countries such as the Philippines, Indonesia, Malaysia, Nigeria, Ghana, Kenya, Zambia, Tanzania and Mozambique.

Typical Technical Parameters

• Rated Voltage: 380V / 400V / 415V / 440V AC
• Frequency: 50Hz / 60Hz
• Rated Current: 100A–6300A
• ATS Type: PC Class / CB Class
• Transfer Mode: Automatic / Manual / Automatic + Manual
• System: 3P+N / 3P+PE / 3P+N+PE
• Protection: MCCB / ACB / Fuse options
• Enclosure: Indoor or outdoor cabinet, typically IP31–IP55
• Standards: IEC 61439, IEC 60947-6-1 and related local requirements

FAQ
Q1: Can the ATS switch between utility power and a diesel generator?
A: Yes. The ATS can monitor both power sources and automatically transfer the load when the preferred source fails and return it after power restoration.

Q2: What voltage can you manufacture?
A: Common configurations include 380V, 400V and 415V AC. Other voltage systems can be customized according to the project requirement.

Q3: Can the cabinet be supplied with an ACB instead of MCCB?
A: Yes. ACBs are suitable for high-current applications, while MCCBs are commonly used for smaller distribution capacities.

Q4: Can you customize the cabinet dimensions and cable entry?
A: Yes. Incoming/outgoing cable direction, busbar arrangement, cabinet dimensions, protection devices and feeder configuration can be customized.

Q5: Is it suitable for tropical countries?
A: Yes. For Southeast Asian and African projects, anti-condensation heaters, ventilation, suitable enclosure protection and other environmental adaptations can be provided.
