| Technical information |
| Encryption |
1024-bit RSA, 128-bit AES, 2048-bit RSA, 256-bit AES-CBC, 256-bit AES-GCM, 256-bit SHA, 384-bit SHA, 512-bit SHA, 748-bit RSA, DES, ECDSA 256-bit, ECDSA 384-bit, ESP, HMAC, IKE, MD5, PKI, SHA-1, SHA-2, TLS, Triple DES |
| Max Operating Temperature |
104 degree Fahrenheit |
| Min Operating Temperature |
32 degree Fahrenheit |
| MTBF |
536,060 Hours |
| Operating Humidity |
5 - 85% (non-condensing) |
| Operating System Required |
Cis-co IOS XE 17.3.2 |
| Supported Devices |
2 |
| Product information |
| Authentication Method |
RADIUS, Secure Shell (SSH) |
| Capacity |
Access Control Entries (ACEs) per system (IPv4): 72000, ACL: 4000, Firewall sessions: 512000, IPv4 routes: 1600000, IPv6 routes: 1500000, Maximum overlay tunnels: 6000, NAT sessions: 1200000, Queues: 16000, Virtual Routing and Forwarding (VRF) entries: 4000 |
| Device Type |
Internal power supply |
| Installed Devices/Modules |
0 |
| Packaged Quantity |
1 |
| Service Activation |
No |
| VoIP Protocols |
SRTP |
| Bridge & Router |
IPv4 forwarding throughput (1400-byte packet size): 19.7 Gbps, VPN throughput (1400 B IPSec): 1.9 Gbps, VPN throughput (IMIX IPSec): 5 Gbps |
| Dimension and weight |
| Height |
1.7 inch |
| Height (Rack Units) |
1 |
| Weight |
20 lbs |
| Width |
17.5 inch |
| Depth |
16.3 inch |
|
