48-Port Gigabit + 16 SFP Data Center Switch High Density , 10G Uplink , IRF Stacking
48-Port Gigabit + 16 SFP Data Center Switch High Density , 10G Uplink , IRF Stacking
Specifications
Brand Name :
H3C
Model Number :
LS-6116-48X-M
Security :
ACL, CoPP, MACsec
Speed :
1/10/25/40/50/100/400 Gbps
Modular Design :
Yes
Management Interfaces :
CLI, Web GUI, REST API
Power Supply :
Dual redundant hot-swappable
High Availability :
Virtual PortChannel, FabricPath, ISSU
Security Features :
MACsec, ACL, CoPP, TrustSec
Redundancy :
N+1 or N+N redundancy
Features :
Virtual PortChannel, FabricPath, VXLAN, ACI
Management Interface :
CLI, Web GUI, SNMP
Uplink Interfaces :
Up to 8 x 40/100-Gbps QSFP28 ports
Virtualization Support :
VLAN, VXLAN, VRF
Description

48-Port Gigabit + 16 SFP Data Center Switch High Density , 10G Uplink , IRF Stacking

The H3C LS-6116-48X-M is a high-performance data center switch designed for enterprise and mid-sized networks, offering 48×1G RJ45 ports and 16×SFP fiber slots for flexible connectivity. With 10G uplink support, IRF stacking, and advanced security features, it delivers reliable, low-latency switching for bandwidth-intensive applications like virtualization, cloud services, and storage networks.

Key Features

  • High-Density Ports: 48×10/100/1000BASE-T ports + 16×1G SFP slots (fiber/copper) for versatile deployments.

  • 10G Uplink Ready: Optional 10G SFP+ modules enable high-speed aggregation to core switches or servers.

  • IRF Intelligent Stacking: Combine up to 9 switches as a single logical device, simplifying management and scaling ports.

  • Enterprise Reliability: Supports LACP, RSTP/MSTP, and dual redundant power supplies (optional) for fault tolerance.

  • Advanced Security: ACLs, 802.1Q VLAN, and port isolation protect against unauthorized access.

  • Energy Efficiency: Complies with IEEE 802.3az (EEE), reducing power consumption by up to 30%.

Technical Specifications

Parameter Details
Ports 48×1G RJ45, 16×1G SFP, 4×10G SFP+
Switching Capacity 176 Gbps
Forwarding Rate 131 Mpps
Memory 4GB DDR4
Power Supply 1+1 Redundant (Optional)
Management CLI, Web, SNMP, H3C iMC
Dimensions 440×420×44 mm (Rack-mountable)

Ideal Use Cases

  • Data Center Access Layer: Connect servers, NAS, and hyper-converged infrastructure.

  • Enterprise Campus: High-density wired access for offices, IP cameras, and VoIP.

  • ISP Edge Networks: Fiber aggregation for broadband or metro Ethernet.

Optimized for scalability and low TCO, the H3C LS-6116-48X-M ensures seamless performance in demanding environments. Contact us for pricing, datasheets, or custom configurations!
