High-Density 10G/40G Data Center Switch IRF2 Virtualization & SDN Support H3C LS-6800-54QT-H3
High-Density 10G/40G Data Center Switch IRF2 Virtualization & SDN Support H3C LS-6800-54QT-H3
Specifications
Brand Name :
H3C
Model Number :
LS-6800-54QT-H3
Operating Temperature :
0°C to 40°C
Protocols :
BGP, OSPF, EIGRP, PIM, VRRP, and more
Model :
Nexus 9000 Series
Form Factor :
Rack-mountable
Chassis Options :
Fixed or Modular
Forwarding Rate :
1.08 Bpps
Network Protocols :
TCP/IP, IPv4, IPv6, OSPF, BGP, EIGRP
Switching Capacity :
1.44 Tbps
Data Center Interconnect :
OTV, LISP, MPLS
Management Interface :
1 x RJ-45
Uplink Interfaces :
Up to 8 x 40/100-Gbps QSFP28 ports
Port Density :
48 ports
Scalability :
Up to 9216 ports in a single fabric
High Availability :
Yes
Description

High-Density 10G/40G Data Center Switch IRF2 Virtualization & SDN Support H3C LS-6800-54QT-H3

The H3C LS-6800-54QT-H3 is a high-performance data center switch designed for enterprise core, aggregation, and cloud environments. Featuring 48x 10G SFP+ ports and 6x 40G QSFP+ uplinks, it delivers high-density connectivity with flexible scalability. Supporting IRF2 virtualization, it allows multiple switches to operate as a single logical device, simplifying management and enhancing redundancy.

Key Features:

✔ High-Speed Connectivity – 48x 10G + 6x 40G ports for low-latency, high-bandwidth workloads.
✔ IRF2 Virtualization – Combine multiple switches for simplified management and improved resiliency.
✔ SDN & Cloud-Ready – Supports OpenFlow, VXLAN, and EVPN for software-defined networking (SDN) and multi-tenant cloud deployments.
✔ Advanced QoS & Security – Hardware-based traffic prioritization, ACLs, and anti-DDoS protection.
✔ Energy-Efficient Design – Dynamic power management reduces operational costs.

Technical Specifications:

Parameter Specification
Port Configuration 48x 10G SFP+, 6x 40G QSFP+
Switching Capacity 2.4 Tbps
Forwarding Rate 1,440 Mpps
Virtualization IRF2 (Intelligent Resilient Framework)
SDN Support OpenFlow, VXLAN, EVPN
Redundancy Dual power supplies, hot-swappable fans
Security Features ACL, DHCP Snooping, IP Source Guard

Ideal for data centers, cloud computing, and enterprise networks, the H3C LS-6800-54QT-H3 ensures high availability, scalability, and automation for modern IT infrastructures.
