Industrial-Grade Ethernet Switch With 24x100M & 4x1G Ports , Wide-Temp Support For Harsh Environments
Industrial-Grade Ethernet Switch With 24x100M & 4x1G Ports , Wide-Temp Support For Harsh Environments
Specifications
Brand Name :
H3C
Model Number :
LS-IE4120U-28TP-H1
Port Speed :
10Gbps
Virtualization :
Supports VXLAN, EVPN, and ACI
Application :
Data Center Networking
Ports :
Up to 768 10/25/40/50/100 Gbps ports
Maximum Power Consumption :
1.5 kW
Operating Temperature :
0°C to 40°C
Dimensions :
1.72 x 17.3 x 22.5 inches
Redundancy :
Hot-swappable power supplies and fans
Virtualization Features :
VXLAN, NVGRE, MPLS
Stacking Bandwidth :
160 Gbps
Port :
48/96/144/192/288/384/768
High Availability :
Supports virtual PortChannel, FabricPath, and vPC+
Throughput :
Up to 172.8 Tbps
Flash Memory :
16 GB
Description

Industrial-Grade Ethernet Switch With 24x100M & 4x1G Ports , Wide-Temp Support For Harsh Environments

The H3C LS-IE4120U-28TP-H1 is a rugged industrial-grade Ethernet switch designed for harsh environments, featuring 24x 10/100M ports and 4x Gigabit combo ports (SFP/RJ45) for high-speed connectivity. Built to withstand extreme conditions, it operates in a wide temperature range (-40°C to 75°C) and offers IP40 protection against dust and EMI interference, making it ideal for industrial automation, smart transportation, and power utility networks.

Key Features & Benefits

✔ Industrial Durability – Fanless design, DIN rail mounting, and 12-48V DC/24V AC dual power input ensure reliable operation in demanding settings.
✔ High-Speed Networking – 4x Gigabit uplink ports (SFP or copper) enable seamless backbone connectivity.
✔ Fast Redundancy – Supports ERPS (Ethernet Ring Protection Switching) with <50ms failover, minimizing downtime.
✔ Industrial Protocol Support – Optimized for Profinet, Ethernet/IP, and IEEE 1588v2 (PTP) for precise synchronization.
✔ Advanced Security & QoS – Features VLAN, ACL, 802.1X authentication, and traffic prioritization for secure, stable data transmission.

Technical Specifications

Parameter Specification
Ports 24x 10/100M RJ45 + 4x 1G Combo (SFP/RJ45)
Switching Capacity 12.8 Gbps
Operating Temp. -40°C to 75°C
Power Input 12-48V DC / 24V AC (redundant optional)
Protection Rating IP40, EMI Level 4
Redundancy Protocols ERPS, STP/RSTP/MSTP
Management Web, CLI, SNMP, H3C iMC

Ideal Applications

  • Factory Automation (IIoT, PLC networks)

  • Transportation (Railway, Traffic Control)

  • Energy & Utilities (Smart Grid, Substations)

This industrial Ethernet switch delivers high reliability, fast recovery, and secure connectivity for mission-critical networks. DIN rail mounting and wide-temperature operation make it a top choice for harsh industrial deployments.
