Specifications
Brand Name :
Ruijie
Model Number :
RG-AP180-L(V3)
Management Interface :
Web, CLI, SNMP
Warranty :
1 year
Security Protocols :
WPA/WPA2, WEP, 802.1X
Weight :
0.5kg
Power Over Ethernet (Poe) Support :
Yes
Maximum Data Transfer Rate :
1.167Gbps
Frequency Band :
2.4GHz/5GHz
Maximum Power Consumption :
12W
Mounting Options :
Ceiling, Wall
Antenna Type :
Internal
Number Of Antennas :
2
Wireless Standard :
802.11ac
Description

High-Density WiFi 6 & MU-MIMO Support Secure 802.11ac Wave 2 Wireless AP Ruijie RG-AP180-L(V3)

The Ruijie RG-AP180-L(V3) is a high-performance dual-band wireless access point (AP) designed for enterprise and high-density environments, delivering seamless connectivity, advanced security, and intelligent RF optimization. Supporting 802.11ac Wave 2 and WiFi 6-ready technologies, this AP ensures high-speed wireless access with a combined throughput of up to 1.567Gbps (300Mbps on 2.4GHz + 1.267Gbps on 5GHz).

Key Features & Benefits

High-Density Performance – 4×4 MU-MIMO technology allows multiple devices to connect simultaneously without lag, ideal for conference rooms, classrooms, and offices.
Smart RF Optimization – Automatically adjusts channel selection & power settings to minimize interference and maximize coverage.
Enterprise-Grade Security – Supports WPA3 encryption, VLAN isolation, and anti-ARP spoofing to protect against cyber threats.
Flexible Deployment – PoE-powered (802.3af/at) for easy installation and wall/ceiling mount options.
Cloud & Centralized Management – Compatible with Ruijie RG-AC controllers & cloud platforms for remote monitoring and troubleshooting.

Technical Specifications

Parameter Details
Wireless Standards IEEE 802.11a/b/g/n/ac Wave 2
Max. Speed 1.567Gbps (2.4GHz: 300Mbps + 5GHz: 1.267Gbps)
MIMO Configuration 4×4:4 (4Tx, 4Rx)
Security WPA3, WPA2, 802.1X, MAC filtering, rogue AP detection
Ethernet Port 1× Gigabit (PoE-supported)
Power Supply 802.3af/at PoE or DC 12V
Mounting Wall/Ceiling
Management Ruijie Cloud, RG-AC Controller

Ideal Use Cases

  • Corporate offices with high user density

  • Educational institutions (lecture halls, labs)

  • Healthcare & retail for secure guest WiFi

With high-speed connectivity, intelligent RF management, and robust security, the Ruijie RG-AP180-L(V3) is a reliable choice for businesses seeking scalable, future-proof wireless networking.
