Specifications
Brand Name :
Huawei
Model Number :
Netengine Ar6280
Certification :
CQC
Place of Origin :
China
MOQ :
1 unit
Price :
1020-1500USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 units
Delivery Time :
7 work days
Packaging Details :
Original brand carton
Product Name :
Enterprise Routers
Part Number :
02115641
First supported version :
V300R019C11
type :
dual sim 5g lte route
Description

Netengine Ar6280 02115641 1*SRU Slot, 4*SIC Slot, 2*WSIC Slot Enterprise Routers

Description

The AR600 series routers deliver unmatched openness, on-demand service provisioning, and easy deployment, and offer cost-effective and easy-to-maintain networks with flexible services, making them ideal for small branches. The AR6100&AR6200&AR6300 series Enterprise routers provide a broad range of options for customers of all sizes across industries to best suit their extensive application scenarios. Featured products include the NetEngine AR6200 and AR6300 series built for headquarters and large branches and the NetEngine AR6100 series ideal for midsize branches.

Item Details
Description AR6280 integrated chassis, 1*SRU slot, 4*SIC slot, 2*WSIC slot, 2*XSIC slot, 2*power slot
Part Number 02115641
Model AR6280
First supported version V300R019C00
Remarks

All the indicators seen on the AR6280 front panel are module indicators. For details about these indicators, see indicator description of the specific module.

The AR6280 system specifications depend on the SRU that is used.

Pictures

Netengine Ar6280 02115641 1*SRU Slot 4*SIC Slot 2*WSIC Slot Enterprise Routers

Netengine Ar6280 02115641 1*SRU Slot 4*SIC Slot 2*WSIC Slot Enterprise Routers

Specification

Item Specification
Installation type Rack
Chassis height [U] 2 U
Dimensions without packaging (H x W x D) [mm(in.)]
  • Basic dimensions (excluding the parts protruding from the body): 88.1 mm x 442.0 mm x 470.0 mm (3.47 in. x 17.4 in. x 18.5 in.)
  • Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 88.1 mm x 442.0 mm x 474.0 mm (3.47 in. x 17.4 in. x 18.66 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 185 mm x 585 mm x 740 mm (7.28 in. x 23.03 in. x 29.13 in.)
Weight with packaging [kg(lb)] 12 kg (26.45 lb)
Weight without packaging [kg(lb)] 8.85 (19.51)
Number of service board slots 8
MIC slots (default/maximum) 0/0
SIC slots (default/maximum) 4/4
WSIC slots (default/maximum) 2/6
XSIC slots (default/maximum) 2/2
RPS input Not supported
PoE Not supported
IP rating IP20
MTBF [years] 27.55 years
MTTR [hours] 2 hours
Availability 0.9999929422
Power supply mode Pluggable AC/HVDC and pluggable DC
Number of power modules 2
Rated input voltage [V]
  • Rated AC input voltage: 100 V to 240 V, 50 Hz or 60 Hz
  • Rated DC input voltage: –48 V DC to –60 V DC
Input voltage range [V]
  • Maximum AC input voltage: 90 V to 264 V, 47 Hz to 63 Hz
  • Maximum DC input voltage: –38.4 V DC to –72 V DC
Maximum input current [A] Depending on the power modules that is used
Maximum output power [W] Depending on the power modules that is used
Redundant power supply
  • Double AC power modules (1+1 backup)
  • Double DC power modules (1+1 backup)
Types of fans Pluggable
Number of fan modules 1
Heat dissipation mode Air cooling
Airflow Left-to-right airflow
Noise at normal temperature (acoustic power) [dB(A)] 54.2 dB(A)
Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] < 5000 m (16404.2 ft.)
Storage temperature [°C(°F)] -40°C to +70°C (-40°F to +158°F)
Overtemperature alarm Supported
