02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
Specifications
Brand Name :
Huawei
Model Number :
AirEngine 9700-S
Certification :
CQC
Place of Origin :
China
MOQ :
1 unit
Price :
2690-3100USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 units
Delivery Time :
7 work days
Packaging Details :
Original brand carton
Product Name :
AirEngine 9700-S
Type :
Access Controller
Storage :
NAND Flash 2 GB
Console port :
RJ45
USB :
1 x USB 2.0 (host type A) port
Description

AirEngine 9700-S 02354KMV 10*GE Ports 2*10GE SFP+ Ports WLAN Access Controllers

Description

Huawei AirEngine 9700-S is a wireless access controller (AC) designed for small- and medium-sized enterprise campuses, enterprise branches, and school campuses. In combination with Huawei access points (APs), this AC can be used to construct small- and medium-sized campus networks, enterprise office networks, wireless Metropolitan Area Networks (MANs), and hotspot networks.

The AirEngine 9700-S has the following features:
  • Outstanding capacity and performance: This AC has two SFP+ optical ports and ten GE electrical ports. It can manage a maximum of 256 APs and can provide up to 10 Gbit/s forwarding capability.
  • Great flexibility: This AC supports direct and tunnel data forwarding modes, and provides flexible user permission management with user- or role-based access control.
  • Abundant O&M methods: This AC allows for various network O&M methods, including web system and CLI.
    Item Details
    Description AirEngine9700-S mainframe (10*GE ports, 2*10GE SFP+ ports, with the AC/DC adapter)
    Part Number 02354KMV
    Model AirEngine 9700-S
    First supported version V600R022C00
Pictures

02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+

02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+

Specification

Item Specification
Installation Type
  • Rack
  • Desk
  • Wall
Dimensions without packaging (H x W x D) [mm(in.)]

Basic: 43.6 mm x 250 mm x 210 mm (1.72 in. x 9.84 in. x 8.27 in.)

Maximum: 43.6 mm x 250 mm x 215 mm (1.72 in. x 9.84 in. x 8.46 in.)
Weight without packaging [kg(lb)] 1.9kg
Storage NAND Flash 2 GB
Console port RJ45
Maximum power consumption [W] 25.06 W
Maximum heat dissipation [BTU/hour] 85.50 BTU/hour
Power supply mode DC adapter
Service port surge protection 6 kV in common mode
Types of fans None
Maximum number of physical ports on the entire device 2 x 10GE (SFP+) + 10 x GE (RJ45)
Long-term operating temperature [°C(°F)] 0°C to 45°C (32°F to 113°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.)
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground Ground
USB 1 x USB 2.0 (host type A) port
MTBF [year] 50 year
MTTR [hour] 2 hour

02354KMV WLAN Access Controller AirEngine 9700-S 10*GE 2*10GE SFP+
