ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router
Specifications
Brand Name :
Huawei
Model Number :
ME60-X3
Certification :
CQC
Place of Origin :
China
MOQ :
1 unit
Price :
1060-2000USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 units
Delivery Time :
7 work days
Packaging Details :
Original brand carton
Product Name :
Enterprise Service Router
Part Number :
02355493
Application :
Telecommunication
Wi-Fi Transmission Standard: :
802.11ac
Description

ME60-X3 02355493 ME0B0BKPA331 Integrated AC Chassis Enterprise Service Router

Description

The ME60 series is a range of multiple-service enterprise router — a type of Broadband Remote Access Server (BRAS) — developed by Huawei to serve as a platform for unified user access and management, and most suitable for industries such as broadcasting, television, and education. Based on a 2T platform, the series boasts the industry’s largest-capacity routing line card (480G) plus a large-capacity NAT service line card (160G), enabling smooth evolution from IPv4 to IPv6.

Pictures

ME60-X3 Enterprise Service Router ME0B0BKPA331 Integrated AC Chassis Router

Specification

Wide [mm]
442 mm
Depth [mm]
650 mm
Height [mm]
220 mm
Chassis height [U]
5 U
Weight without packaging [kg(lb)]
25 kg (55.12 lb)
Weight without packaging (full configuration) [kg(lb)]
52 kg (114.64 lb)
Typical power consumption (with configuration) [W]
950 W (fully configured with BSUF-51s) 1070 W (fully configured with BSUF-120s) 1386 W (fully configured with BSUF-241s)
Maximum power consumption (with configuration) [W]
1130 W (fully loaded with BSUF-51s) 1260 W (fully loaded with BSUF-120s) 1669 W (fully loaded with BSUF-241s)
Typical heat dissipation (with configuration) [BTU/hour]
3082.2 BTU/hour (fully configured with BSUF-51s) 3471.5 BTU/hour (fully configured with BSUF-120s) 4496.8 BTU/hour (fully configured with BSUF-241s)
Maximum heat dissipation (with configuration) [BTU/h]
3666.2 BTU/hour (fully loaded with BSUF-51s) 4088 BTU/hour (fully loaded with BSUF-120s) 5414.9 BTU/hour (fully loaded with BSUF-241s)
Power supply mode
AC built-in
Rated input voltage [V]
200 V to 240 V
Input voltage range [V]
180 V to 264 V
Maximum input current [A]
12A/single-module
Number of service board slots
3
Number of slots
5
Redundant MPUs
1:1
Redundant fans
Support for proper fan operation in case of a single fan failure for a short period at 40°C (104°F)
Redundant power supply
1+1
Noise at normal temperature (acoustic power) [dB(A)]
ETSI-compliance (<72dBA @ 23°C (73.4°F))
Maximum number of power chassis inputs
(1 channel/PEM)*2 PEM=2 channels
Maximum input cable size
Standard C19 cable
Front-end circuit breaker/fuse
16 A
Long-term operating temperature [°C(°F)]
0°C to 45°C (32°F to 113°F)
Short-term operating temperature [°C(°F)]
-5°C to 55°C (23°F to 131°F)
Storage temperature [°C(°F)]
-40°C to 70°C (-40°F to 158°F)
Restriction on the operating temperature variation rate [°C(°F)]
≤ 30°C/hour (86°F/hour)
Long-term operating relative humidity [RH]
5% RH to 85% RH, non-condensing
Short-term operating relative humidity [RH]
5% RH to 95% RH, non-condensing
Storage relative humidity [RH]
5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)]
≤ 4000 m (13123.2 ft.) (For the altitude in the range of 1800 m to 4000 m [5905.44 ft. to 13123.2 ft.], the operating temperature of the device must decrease by 1°C [1.8°F] for every 220 m [721.78 ft.].)
Storage altitude [m(ft.)]
< 5000 m (16404 ft.)
MTBF [year]
34.76
MTTR [hour]
0.5
Availability
0.999998358
