Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
Specifications
Brand Name :
WONTERM
Model Number :
WT5801
Certification :
CE/FCC/UL/ROHS
Place of Origin :
China
MOQ :
30pcs
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
30000m per month
Delivery Time :
10 working days after received your payment
Packaging Details :
305/box
Nominal Outer Diameter :
5.0mm
Conductor Material :
Copper
HS Code :
8544491100
Size of Conductor :
24 American Wire Gauge
Numbers of Conductor :
8
Description

100m Category 5e networks 0.5mm Twisted pair BC PVC fluke test 24 American Wire Gauge

Specifications:

1. Cable Inner material: OFC/PURE COPPER/CCA/CCA/AL/Aluminum Foil Shielded twisted pairs, FRPE cable
2. LAN cable Conductor: 4 twishted pairs cabled around a cross shaped central filler into the cable core.
3. Insulation: PE Polyethylene, 0.90+/-0.05mm HDPE
4. Jacket: PVC
5. Colour:grey,blue,red,yellow,green,black,white, also as customers requirements.
6. Compliance: ETL verified ANSI TIA/EIA568-2, UL, Subject 444, (UL)c(UL) type CMR/CMG, Type CM/CMH. NEC Srticle 800Type CMP or CM. ISO/IEC 11801. RoHS Compliant.
7. Application: 100Base-TX, 100VG-AnyLan, 1000Base-T, ATM, Noisy Environment
8. Remark: 250HMZ 550MHz ATM 155MBPS, 100mbps TPDDI, Fast Ethernet etc, Cat3, cat5e, cat6 are avilable, and cat5e and cat6 are already.

Category Cat5 cable
Structure Type UTP
Conductor Bare copper
Pair 4 pairs
Awg 24AWG/26AWG
Solid/Stranded Stranded
Insulation Material Color-coded PE
Outer Jacket Material PVC/ROHS
Color by customized order
Length by customized order
Reference Standard Category 5 UL444, ANSI/TIA/EIA 568B & ISO/IEC 11801 Standard
Rated Temperature -20° to +75°
Supports transmission Digital and analogue voice, data and video signal

Description:

Operating temperature: -20°C to +75°C

Bare copper, PE insulation, FR PVC/LSOH PVC RoHS jacket


Standards:
ISO/IEC11801, ANSI/TIA/EIA-568B

Certification: UL. CE. RoHS Compliant

Applications:

Used as work-station oution to the FD/IDF and other horizontal cabling,

supporting TP-PMD Audio,

integrated service digital network(ISDN),

ATM 155Mbps, 1Gmbps TPDDI, Fast Ether-net etc.

Electrical Performance:


Conductor Resistance		 Max. 9.38 ohm/100m
Resistance Unbalance Max. 2%
Insulation Resistance 150 ohm/KM
Mutual Capacitance Max. 5600pF/100m
Capacitance Unbalance Max. 330pF/100m
Impedance 100+/-15 ohm
Spark Test 2000V
Velocity of Propagation 67%

Network 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm TwistedNetwork 100m UTP Bare Copper Category 5e / Cat5e UTP Cable , 0.5mm Twisted
