Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Chenye
MOQ :
1
Price :
$31,800-35,800
Power :
5.5 W
Knitting style :
Warp
Knitting method :
Single
Computerized :
Yes
Gauge :
3 GG, 2 GG
Knitting width :
120 inch
Core components :
Motor
Knot type :
E6,E7,E8,E9,E12,E14
Automatic grade :
Manual
Working width :
110'',135'',150'',180'',220'',260'',340''
Needle type :
Latch Needle
Bar number :
2~6
Nominal width :
135" 150" 180" 220" 260"
Take-up manner :
2 rollers with friction drive,center shaft drive; 2 rollers with friction drive,separately-standing, center shaft drive, separately-standing
Speed :
200-480 row/minute
Description
Product Description

SROP High Speed Single Needle Bar Raschel Machine
APPLICATION:This machine is used to produce mosquito net,plaid net,purse net and chemical fiber garment net.
FEATURES:The machine is equipped with open camgearing ,the negative yarn let-off system
Usage:The machine can produce mosquito net,plaid net,purse net and chemical fiber garment net.
Features: The machine is equipped with open cam gearing, the negative yarn let-off system.
Needle Type
Latch Needle
Gauge
E6, E7, E8, E9, E12, E14, E16, E18
Bar Number
2~6
Nominal Width
135" 150" 180" 220" 260"
Take-up Manner
2 rollers with friction drive,center shaft drive;
2 rollers with friction drive,separately-standing,
center shaft drive, separately-standing

Machine Type
Machine Size(L*W*H)(mm)
Machine Weight(Kg)
Motor Power(Kw)
Speed(row/minute)
Main Motor
Inching Motor
SROP-135
4300*2200*2700
~4700
3
0.37
200-480
SROP-150
4900*2200*2700
~5000
4
0.37
200-480
SROP-170
5800*2400*2800
~7500
5.5
0.75
200-420
SROP-220
7300*2400*2800
~9000
5.5
1.5
200-420
SROP-240
7600*2400*2800
~10500
5.5
1.5
200-380


What products we can produce by this machine?

Company Information

Exhibition

Producing

Our Services

1.We can dispatch our enginner to your factory to commissioning machine and trainning your enginner.
2.You can dispatch your enginner come to our factory to study how to maintance and fix machine.We will arrange netting factory to
teach your enginner study how to produce net for free.
3.Our service team online 24 hours to help you solve problems.
4.Some contries we have office and local enginner to provide you professional service.
5.If we go to your contry to attend exhibition or visit customers,we must go to your factory to maintance machine for free.
