Popular Warp Knitting Machine Models for Agricultural and Industrial Nets
Popular Warp Knitting Machine Models for Agricultural and Industrial Nets
Specifications
Model Number :
SRCA
Payment Terms :
L/C,T/T,Western Union
Color :
Customized
Size :
2m/2.5m/3.4m/3.8m/4.5m/5.5m/6m/6.6m/8.6m/9.6m/11m
Price :
Negotiation
Working Width :
135"-260"
Supply Ability :
25 sets per month
Product Type :
Shade net making machine
Speed :
200-450rpm
MOQ :
1 set
Delivery Time :
60 days after deposit payment
Warranty :
1Year(lifelong Technical Support)
Place of Origin :
China , Jiangsu
Packaging Details :
40HQ/Set
Certification :
ISO ,CE, TUV
Brand Name :
Chenye
Description
Popular Warp Knitting Machine Models for Agricultural and Industrial Nets

Net manufacturing requires specialized warp knitting machines capable of producing strong and durable mesh structures. Several machine models are widely used throughout the industry.

Product Overview
Number of bars: 2-8
Working Width: 135", 150", 170", 220", 240", 260"
Take-up manner: 2 rollers with friction drive, center shaft drive, separately-standing
Feature: The machine is equipped with oiled eccentric gearing and the negative yarn let-off system.
Needle Type: Block latch needle, individual latch needle or Compound needle
Gauge: E3, E6, E7, E8, E9, E12, E14, E16, E18
Machine Parameters
Type Size (L×W×H) Weight (Kg) Power (KW) Speed (rpm)
SRCA-135 4300×2200×2700 4700 3 200-530
SRCA-150 4900×2200×2700 5000 3 200-530
SRCA-180 6100×2200×2700 7500 5.5 200-530
SRCA-220 7300×2200×2700 9000 5.5 200-530
SRCA-260 8200×2200×2700 11000 7.5 200-480
SRCA-340 10300×2200×2700 14000 11 200-450


The RS180 model is suitable for producing smaller-width agricultural and packaging nets. Its compact design makes it ideal for medium-scale manufacturers.The RS220 model is commonly used for bale nets, agricultural nets, and packaging applications. It offers a good balance between production capacity and investment cost.The RS260 model is one of the most popular choices for shade net production, fishing nets, and protective nets. Its wider working width and stable operation make it highly efficient for commercial manufacturing.The RS340 model is designed for large-scale industrial production. With its increased working width and advanced configuration, it can meet the demands of high-volume net manufacturing.

When choosing a machine model, manufacturers should evaluate production requirements, target markets, product specifications, and investment budgets to ensure the best return on investment.


A suitable machine model can significantly improve production efficiency, product quality, and long-term business competitiveness.



Popular Warp Knitting Machine Models for Agricultural and Industrial Nets


Popular Warp Knitting Machine Models for Agricultural and Industrial Nets


Packing and Shipping
We ensure the safety and secure packaging of all goods during transportation and delivery.
Popular Warp Knitting Machine Models for Agricultural and Industrial Nets Popular Warp Knitting Machine Models for Agricultural and Industrial Nets
Frequently Asked Questions
1. What is the output of shading net making machine?
Output depends on machine working width and net specifications, typically ranging from 500-1000KG per 24 hours.
2. How much space needed to set up a shading net production line?
Small-scale production requires 100-200 square meters, while larger lines may need several thousand square meters, including space for machines, raw materials, and finished products.
3. How many kinds of shading net can be produced by rascheal warp knitting machine?
Four types can be produced: mono+mono yarn shading net, mono+flat yarn shading net, mono+flat yarn shade net, and Al+pet yarn shade net.
4. Are the machines customizable for different net specifications?
Yes, modern machines are customizable for various sizes, mesh configurations, and materials to meet specific shading requirements.
5. What types of shading nets material can be made with these machines?
Primarily HDPE material, with some applications using AL and PET materials for specialized shading nets.
6. Are there any special skills required to operate the machine?
Operating requires training for optimal performance. We provide comprehensive training sessions and manuals covering setup, operation, and maintenance procedures.
