Specifications
Model NO. :
WIND-ZR190
Winding Service :
Engineers Avaiable to Service Overseas
Condition :
New
Customized Service :
Provided
Automatic :
Semi-Automatic
Transport Package :
Wooden Case
Specification :
Middle Size
Trademark :
Wind Automation
Origin :
China
HS Code :
8479811000
Production Capacity :
100 Sets/Year
Package Size :
1100.00cm * 800.00cm * 1500.00cm
Package Gross Weight :
550.000kg
Description
Alternaotr Generator Motor Armature Coil Winding Machine
Alternaotr Generator Motor Armature Coil Winding Machine

Adapting special purpose controller, this machine is suitable for winding various small alternator armature with copper wire or aluminum wire. Winding speed, arraying speed, indexing and clamping are well controlled. It could wind 2pcs armature simultaneously, after completing one side armature, the system will automatically turn around and start to wind another side. Winding tension is adjustable and arraying is even.


Specification

Armature OD Max 150mm
Stack height 50~190mm
Tooling travel Max 200mm
Slot number Max 4
Power supply 220V 0.75KW
Weight About 550KG
Dimension 1100x800x1500mm


Alternaotr Generator Motor Armature Coil Winding MachineAlternaotr Generator Motor Armature Coil Winding Machine
Alternaotr Generator Motor Armature Coil Winding Machine
