FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector
FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector
FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector
FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector
Specifications
Brand Name :
HUATEC
Model Number :
FJ-3025
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T,Paypal
Supply Ability :
10sets/Month
Delivery Time :
5-7 working days after receipt of your payment
Packaging Details :
Carton packing box
Measurement range :
0.01μSv/h～500μSv/h
Energy response :
40keV～3MeV
Sensitivity :
350cps/ μSv/h
Relative error, not more :
±15%
Description

FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector


Features:
Real-time measurement of γ and X-ray radiation in the workplace
Features a 485 communication interface and supports Modbus protocol
Compatible with host control equipment or upper-level monitoring software
High-sensitivity NaI scintillator detector


Technical Specifications

Measurement range

0.01μSv/h～500μSv/h

Energy response

40keV～3MeV

Sensitivity

350cps/ μSv/h

Relative error, not more

±15%

Response time

≤1s(10μSv/h)

Operating temperature range

-20℃～+50℃

Relative humidity

≤98％

Supply voltage

DC 7V～24V

Static power consumption

12V/ 5mA

Dimensions

Diameter 45mm, Length 120mm (excluding plug height)

Weight

0.6kg


Delivery kit:
Probe, data communication protocol or specialized data analysis software

FJ-3025 High Sensitivity X Gamma Radiation Monitoring Probe NaI Scintillation Detector
