TG-1620 Magnetic Coating Thickness Gauge for Steel Iron Non Magnetic Coating
TG-1620 Magnetic Coating Thickness Gauge for Steel Iron Non Magnetic Coating
TG-1620 Magnetic Coating Thickness Gauge for Steel Iron Non Magnetic Coating
TG-1620 Magnetic Coating Thickness Gauge for Steel Iron Non Magnetic Coating
Specifications
Brand Name :
HUATEC
Model Number :
TG-1620
Certification :
CE
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
T/T,Western Union,Paypal
Supply Ability :
10 Sets/Month
Delivery Time :
7-10 working days after receipt of your payment
Packaging Details :
Outer carton packaging
Measuring range :
0-1500μm
Using environment :
0℃-50℃ and 20%RH—90%RH,not strong magnetic place.
Measurement accuracy :
±（3%H+1.5μm）
Resolution ratio :
0.1μm /1μm
Minimum curvature :
bugle 5mm;concave 25mm
HumidityThe thinnest matrix :
0.4mm
Description

TG-1620 Magnetic Coating Thickness Gauge for Steel Iron Non Magnetic Coating


TG-1620 Coating thickness gauge, test Magnetic thickness method, can be nondestructively measuring magnetic metal matrix (such as: steel, iron, nickel) on non magnetic coatings thickness (such as: galvanized, chrome, paint, electrophoresis, enamel, rubber, powder coating, enamel, etc.)


Technical parameters:

Measuring range 0-1500μm
Using environment 0℃-50℃ and 20%RH—90%RH,not strong magnetic place.
The thinnest matrix 0.4mm
Measurement accuracy ±(3%H+1.5μm)
Resolution ratio 0.1μm /1μm
Minimum curvature

bugle 5mm;concave 25mm
Minimum matrix 18*15mm
Power three (7) alkaline battery
Size 126mm*64mm*28mm
Weight 106g (excluding battery)

TG-1620 Coating thickness characteristics

A, The use of alloy integrated probe, the world's leading technology

B, Simple operation, fast testing speed and high sensitivity.

C, Exquisite artificial integration design, easy to carry.

D, Two test methods: continuous testing (CONT INUE) and single (SINGLE) measurement.

E, Statistical functions: maximum (MAX), minimum (MIN), average (MEA)

F, Which can store 2000 measurement data (10 sets of data).

G, Can connect to the computer for communication, read out and store data for preservation or printing.

H, Two calibration modes: zero calibration and two point calibration.

I, There are beep prompts in operation process (single measurement mode).

J, Automatic identification of iron-based and non-ferrous base materials

K, Low voltage indication

L, Manual / automatic shutdown function

M, Super LCD display backlight, with screen rotation inversion function.

N, Unit conversion μm/mil
