TG-7522FN Digital Coating Thickness Meter for Petroleum Shipbuilding Industry
TG-7522FN Digital Coating Thickness Meter for Petroleum Shipbuilding Industry
TG-7522FN Digital Coating Thickness Meter for Petroleum Shipbuilding Industry
TG-7522FN Digital Coating Thickness Meter for Petroleum Shipbuilding Industry
Specifications
Brand Name :
HUATEC
Model Number :
TG-7522FN
Certification :
CE
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
T/T,Western Union,Paypal
Supply Ability :
10 Sets/Month
Delivery Time :
7-10 working days after receipt of your payment
Packaging Details :
Outer carton packaging
Measuring range :
0-1000um
Measurement accuracy :
±1-3%n or ±2.5um
Resolution ratio :
0.1μm /1μm
Min. measuring area :
6mm
Min. sample thickness :
0.3mm
Description

TG-7522FN Digital Coating Thickness Meter for Petroleum Shipbuilding Industry


Product synopsis

Application:used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.in industries of petroleum,shipbuilding,power station,and machine manufacturing.

Technical Parameters:

Operating principle magnetic induction/eddy current (F/NF)
Measuring range 0-1000um
Resolution 0.1/1
Accuracy ±1-3%n or ±2.5um
Min. measuring area 6mm
Min. sample thickness

0.3mm
Battery indicator low battery indicator
Metric/ imperial convertible
Power supply 4x1.5V AA(UM-3)battery,

Auto power off
Operating conditions

0-+45℃(32℉-104℉),≤90%RH
Dimensions 160x68x32mm
weight 250g(not including battery)
Optional accessories

other range 0-200um to 15000um
