DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
DG-4020 Dual AC&DC operation handheld LED-UV Lamp
Specifications
Brand Name :
HUATEC
Model Number :
DG-4020
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T,Western Union
Supply Ability :
carton
Name :
Handheld LED-UV Lamp
Standard :
ASTM E3022
Application :
Observation light source for fluorescence detection
UV(Light)-FLUX :
6000uW/cm2
Description

DG-4020 Dual AC&DC operation handheld LED-UV Lamp

The ultraviolet lamp in industrial NDT is mainly used to excite fluorescent materials to emit light, thereby making visible defects or traces that are not visible under visible light. It is a key tool for observing and enhancing defect display.
Core application: Observation light source for fluorescence detection.

Project

Parameter / mode

Style

Handheld

UV(Light)-FLUX

Indoor temperature 25℃

6000uW/cm2

White light content

≤3LUX

Irradiation area at depth of 380mm:

(≥1000uw/cm²)

Φ300mm

Flux error

0-40℃ ±10%

Light distribution characteristics

Central light distribution

Power Supply

AC100- 240V,50/60Hz

Power

UV LED-12VA

Wavelength

Room temperature 25℃, 365nm±3nm (UVA)

Overall dimension

157. 5mm (W) *76mm (D) *177mm (H)

Weight

560g including battery

Battery capacity

2200mA/H 12.6V

Charging time

2-3H

Battery life (cumulative time)

UV LED 2-3H

The ultraviolet lamp itself is not a detection method, but a key equipment used in conjunction with specific detection materials (mainly fluorescent penetrant and fluorescent magnetic powder).
