Specifications
Model Number :
D4 D5 D7
MOQ :
1 pc
Packaging Details :
Wooden packing box
Supply Ability :
5sets/Month
Scratch resistance in processing :
≥0.8N
product shelf life :
30 months
Certification :
CE
Payment Terms :
T/T,Paypal
storage conditions :
temperature 10℃ ~ 23℃, relative humidity 30% ~ 65%
Delivery Time :
10-15 working days after receipt of your payment
Alkali soluble time :
≥10
Place of Origin :
China
Film Specification :
356mm×432mm（14in.×17in.）、305mm×381mm（12in.×15in.）、260mm×360mm （10in. ×14in.）、70mm×300mm、80mm×150mm、80mm×240mm、80mm×300mm、80mm×360mm、 100mm×356mm、195mm×275mm、70mm×200m、80mm×100m、80mm×200m
Brand Name :
HUATEC
Description

Industrial X-Ray Radiographic Film High Contrast Fine Grain NDT Weld Casting Inspection Film Equivalent Agfa


Features and uses
Industrial X-ray film is a kind of high resolution and high image resolution film which is widely used in nondestructive flaw detection. The film has high sensitivity, high contrast, high definition,

It can be directly or with lead sensitization screen for X or γ ray exposure. It is suitable for electronic components, synthetic materials, casting and casting, welding, etc.

NDT testing for shipbuilding, national defense and nuclear industry, aerospace and aviation industry, etc. Using blue polyester sheet base, two sides coated with emulsion layer, layer and

Protective layer. This film has rich layers, high image resolution and good definition. This film can be processed at room temperature, also can be processed by high temperature machine.


Product name and model specification

Model

Specification

D4,D4-D,H4,LA400,D5,D5-D,

D7,D7-D,H7,H7-D

356mm×432mm(14in.×17in.),305mm×381mm(12in.×15in.),260mm×360mm (10in. ×14in.),70mm×300mm,80mm×150mm,80mm×240mm,80mm×300mm,80mm×360mm, 100mm×356mm,195mm×275mm,70mm×200m,80mm×100m,80mm×200m


Features and uses


　

GB/T19348.1

EN 584.1

ASTME 1815-08

ISO 11699-1

D4,D4-D,H4

C3

C3

Ⅰ

C3

D5,D5-D

C4

C4

Ⅰ

C4

D7,LA400,D7-D,H7,H7-D

C5

C5

Ⅱ

C5


Product performance

Name of index

unit

D4,D4-D

H4

LA400

D5,D5-D

D7,D7-D,H7,H7-D

Density of fog

--　

≤0.10

≤0.10

≤0.10

≤0.10

≤0.12

Contrast factor “r”

--　

≥4.0

≥3.0

≥3.2

≥4.0

≥3.5

ISO “S”

--　

≥1.5

≥1.0

≥0.6

≥1.5

≥2.0

Alkali soluble time

Minutes

≥10

Scratch resistance in processing

N

≥0.8


Safety lighting and washing processing
The safety operating light in the darkroom of this film is a crimson safety light with a 15W bulb. When the film is used for unsealing, the lamp distance is generally above 1.2 meters. Cumulative illumination time

No more than 40 minutes. The exposed sample should be flushed within 2h. The washing process is shown in the table below.
