HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector
HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector
HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector
HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector
Specifications
Model Number :
HG-6500ANC
MOQ :
1 pc
Packaging Details :
Carton packing box
Supply Ability :
10sets/Month
Display :
LCD display three and a half
Power :
9V laminated battery 1 can be used continuously 25 hours
Certification :
CE
Payment Terms :
T/T,Paypal
Signal Output :
AC 2V peak (full scale and the load is greater than 10K ohms)
Delivery Time :
7-10 working days after receipt of your payment
Sensors :
one rotary shear accelerometer
Place of Origin :
China
Accuracy :
5% ± 2 vibration words
Brand Name :
HUATEC
Description

HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector


Description:
HG-6500ANC Pocket vibration temperature instrument, mainly used in machinery and equipment vibration displacement, velocity (intensity) and the acceleration, temperature parameters of the measurement instrument in the bearing housing using the measured data, the control of international standard ISO2372 , Or the use of enterprises, the standard machine, you can determine the equipment (fans, pumps, compressors, motors, etc.) in which the current state (well, pay attention or dangerous, etc.).


Model Function Frequency range
HG-6500ANC Acceleration, Velocity, Displacement, Temperature 10Hz ~ 10KHz


Specifications

Sensors: one rotary shear accelerometer & Split charge amplifier built-in shear accelerometer

Range: Acceleration 0.1 ~ 199.9m/s2 (single peak) (10 ~ 1KHz; 1K ~ 10KHz)

Speed of 0.1 ~ 199.9mm / s (RMS) (10 ~ 1KHz)

Displacement of 0.001 ~ 1.999mm (peak) (10 ~ 1KHz)

Temperature 0 ℃ ~ 400 ℃

Accuracy: 5% ± 2 vibration words

Temperature 1% ± 1 word

Display: LCD display three and a half

Maintain the characteristics: measurement value is automatically maintained, automatic shutdown delay

Signal Output: AC 2V peak (full scale and the load is greater than 10K ohms)

Power: 9V laminated battery 1 can be used continuously 25 hours

Body volume: 185mm × 68mm × 30mm

Weight: 200g


Standard Configuration:

Main body 1pc

Short Probe 1(only in-built type)

thermocouple transducer 1(only for –C type)

6F22 battery 1

Manual book 1

Quality card/Guarantee Card 1 each


Optional:

Long probe

earpiece

sheath

cable(for signal output)

HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector

HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector

HG-6500ANC Handheld Vibration Analyzer 10Hz ~ 10KHz Acceleration Velocity Displacement Temperature Measurement Bearing Gear Fault Detector
