Specifications
Brand Name :
WLETO
Model Number :
WLT2409-J2
Place of Origin :
Zhejiang, China
MOQ :
20 packs
Price :
$3.15-$3.60
Payment Terms :
T/T, Western Union
Supply Ability :
50000 pcs per day
Delivery Time :
Within 15 days
Packaging Details :
17X6X4.5 cm
Gross Weight :
320g
Color :
Red
Shell Material :
PC
Conductor Size :
1- 5 AWG
Type :
Screw
Pole Material :
304 stainless steel
Description

Bus Bar 12V 250A 4M10+6M4 Studs Marine Battery Automotive Boat

Description:

Brand Name WLETO
Pole Material 304 stainless steel
Shell Material PC
Gross Weight 320g
Place of Origin Zhejiang,China
Conductor Size 1- 5 AWG

Heavy-Duty 250A Power Distribution Hub:
Engineered for automotive, marine, and industrial systems, this 12V bus bar handles 250A continuous loads. Centralizes connections for batteries, alternators, and accessories using 4 corrosion-resistant M10 studs (main lines) and 6 M4 studs (accessories) - ideal for car audio, winches, or solar arrays.

Marine-Grade Copper Core and 304SS Contacts:
Oxygen-free copper busbar ensures minimal voltage drop at peak loads. 304 stainless steel terminals resist saltwater corrosion and electrolysis, maintaining stable connections in engine bays or bilge areas (-30°C to 105°C operating range).

Reinforced PC-Nylon Housing and Safety Cover:
Impact-resistant polycarbonate shell with nylon base withstands fuels, oils, and vibrations. Optional snap-on cover provides IP65 splash protection while allowing visual inspection of connections in high-density electrical panels.

1-5 AWG Universal Compatibility:
Accommodates 1-5 AWG wires across all 10 terminals. Color-coded labels and flared entry ports prevent strand damage during installation - reducing setup time by 40% versus individual lugs in complex systems.

Short-Circuit Prevention and Compliance:
Flame-retardant materials (UL 94V-0) suppress arc faults. Exceeds SAE J1128 and ABYC E-11 standards with integrated insulating barriers between terminals, preventing accidental contact in marine/automotive applications.
