Product Description
Basic Info
Model NO.
12V190
Number of Strokes
Four-Stroke
Cylinder Arrangement Form
V
Number of Cylinders
8-Cylinder
Type
Combustion Engine
Trademark
jichai
Transport Package
Wooden Cases
Specification
2817*1645*2536.5
Origin
China
HS Code
8502200000
Product Description
Customer Question & Answer
Ask something for more details
| Model of genset | Model of engine | Rated Power(KW/KVA) | Rated Voltage(V) | Rated Frequency(HZ) | Overall Dimension L*B*H(mm) | Net weigh(KG) | Fuel |
| 500GF-T1 | G12V190ZLDT1-2 | 500/625 | 400/230 | 50 | 6200*2330*2776.5 | 13800 | natural gas |
| 500GF-T3 | G12V190ZLDT-2 | 500/625 | 400/230 | 50 | 6195*2200*2776.5 | 13800 | natural gas |
| 500GF-TK1 | G12V190ZLDT-2 | 500/625 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | natural gas |
| 500GF-NK | G12V190ZLDZ-2 | 500/625 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | biogas |
| 500GF-WK | G12V190ZLDW-2 | 500/625 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | coal mine gas |
| 500GF-WK2 | G12V190ZLWD2-2 | 500/625 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | coal mine gas |
| 700GF-T1 | G12V190ZLDT1 | 700/875 | 400/230 | 50 | 6200*2330*2776.5 | 13800 | natural gas |
| 700GF-T2 | G12V190ZLDT | 700/875 | 400/230 | 50 | 6100*2314*2600 | 13800 | natural gas |
| 700GF-TK1 | G12V190ZLDT | 700/875 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | natural gas |
| 700GF-NK1 | G12V190ZLDZ | 700/875 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | biogas |
| 700GF-WK | G12V190ZLDW | 700/875 | 400/230 | 50 | 5120*2040*2776.5 | 11800 | coal mine gas |
| Main specification for gas engines | |
| Model | Rated Power(KW) | Rated Speed(r/min) | Compression ratio | No.and layout of cylinders | Overall Dimension L*B*H(mm) | Net weigh(KG) | Fuel |
| G12V190ZLDT | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | natural gas |
| G12V190ZLDT1 | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | natural gas |
| G12V190ZLDT-2 | 550 | 1000 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | natural gas |
| G12V190ZLDT1-2 | 550 | 1000 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | natural gas |
| G12V190ZLDZ | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | biogas |
| G12V190ZLDZ-2 | 550 | 1000 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | biogas |
| G12V190ZLDW | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | coal mine gas |
| G12V190ZLDW-2 | 550 | 1000 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | coal mine gas |
| G12V190ZLWD | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | coal mine gas |
| G12V190ZLWD1 | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | coal mine gas |
| G12V190ZLWD2 | 800 | 1500 | 12:01 | 12,60.Vee | 2817*1645*2536.5 | 5300 | coal mine gas |
| Main technical data | | | | | | | |
| Type:Four stroke,water cooled,turbocharged and aftercooled,spark plug ignition,outer mixing | | | | | | | |
| Bore:190mm | | | | | | | |
| Stroke:210mm | | | | | | | |
| Direction of rotation:Counter-clockwise(facing to flywheel) | | | | | | | |
| Starting method: electric motor | | | | | | | |
| Lubricating method:Pressure and splash lubrication | | | | | | | |
| Specific heat consumption:≤11000KJ/KW·h | | | | | | | |
| Specific oil consumption:≤1.6g/KW·h | | | | | | | |
| Stable speed regulating rate:0-5%adjustable | | | | | | | |

Product Parameters
Jinan Guohua Green Power Equipment Co,Ltd,established in 2010,is a professional high-tech enterprises specialized in power station integration and parts sales,assemble.We invest in chidong 190 diesel engines,gas engines and shengdong 190 diesel engine.With a wealth of professional project engineer,operation experience and advanced scientific management approach,we could satisfied the real needs of customers with the best benefits of power generation program and proper parts provide.

The main business scopes include engine parts(chidong/shengdong 6L190,8V190,12V190,16V190)gas generator and sales, product development, power plant engineering, power station investment, supporting integration, after-sales service.The company has built 1,600 square meters warehouses in Jinan and 1000 square meters warehouse in Xin Jiang.
Over the past seven,in order to solve various problems in gas utilization,we introduce professional gas use technology and gas use-related products.At present the company becomes the larger scale professional parts and units sales company.Because all the parts are original and well-qualified,the company has established long-tem business ship with customers from Russia and Malaysia.

Companies adhere to the purpose of "quality first,scientific management,customer first,integrity-based",which are in accordance with the "integrity,pragmatic,pioneering,innovative" spirit of enterprise,so as to meet the needs of users with first-class service.
Warmly welcome friends from all walks of life to review,cooperate and create brilliance together!
The Company`s Main Products:
190 series gas engine parts,diesel engine parts.
190 series diesel/gas engine and generator.
190 series engine overhaul and maintenance.
OEM gas engine and oil engine.
The operation and maintenance of power station.
Quality Concept:
Quality is the starting point for value,brand and dignity.Quality must meet standards,meet demand,and satisfy customers."Quality first,reputation first."is the company`s unremitting pursuit!
