Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Specifications
Standard :
Standard
Product Material :
Steel
Size :
Small
Transport Package :
Container
Specification :
small
Trademark :
simeno
Origin :
China
HS Code :
8502200000
Supply Ability :
10000
After-sales Service :
Online Services
Warranty :
One Year After Delivery or Accumulative 1500 Hours
Output Type :
DC
Gas Source :
Carbon Monoxide
Certification :
ISO9001
Power :
＞200kW
Customization :
Available | Customized Request
Place of Origin :
china
MOQ :
1
Price :
10-1000
Packaging Details :
Wooden box and carton packaging
Delivery Time :
15 days
Payment Terms :
TT,western
Description
Technical Parameters of Industrial Tail Gas Generator Set
Model 6190 12V190 16V190
CP200GFJ13 CP250GFJ13 CP500GFJ11 CP600GFJ11 CP700GFJ11 CP1000GFJ12
Electric Power,KW 200 300 500 600 700 1000
Waste Heat,KW 253 366 597 713 828 1100
Electrical Efficiency,% 34 36 36 37 38 40
Thermal Efficiency,% 43 44 43 44 45 44
Total Efficiency,% 77 80 79 81 83 84
Cylinder Diameter / Stroke,mm 190/210 190/210 190/210 190/210 190/210 190/210
Number Of Cylinders 6 6 12 12 12 16
Displacement 35.7 35.7 71.4 71.4 71.4 95.2
Speed,r/min 1000/1200 1000/1200 1000/1200 1000/1200 1000/1200 1000/1200
Frequency,Hz 50/60 50/60 50/60 50/60 50/60 50/60
Long,mm 4500 4500 6200 6200 6300 7000
Wide,mm 1300 1300 1950 1950 1950 1900
High,mm 2365 2365 2175 2175 2175 2600
Weight,Kg 7000 8400 11500 12000 12650

24000

It is the first to adopt the split intake double pressurization technology, innovate and develop the patented technology of in cylinder mixing technology and single cylinder control, and use the self-developed fully automatic control system, which is suitable for industrial tail gas containing high carbon monoxide and hydrogen, providing efficient energy equipment for the reuse of industrial combustible gas. It can completely solve the problems of tempering and flash explosion of conventional units, ensure the production safety of the factory and create reliable value for users. The operation of the unit is stable, the annual operation time can reach 8000 hours, which can perfectly adapt to the change of on-site gas source. It has a high degree of automation. While converting tail gas into electric energy, it can achieve power generation efficiency of up to 38%. One cubic meter of tail gas can generate electricity for one time, creating economic and environmental benefits!
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and ProductionSmall Steel Material 20MW Industrial Tail Gas Generator for Sustainable and ProductionSmall Steel Material 20MW Industrial Tail Gas Generator for Sustainable and ProductionSmall Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production Companies adhere to the purpose of "quality first,scientific management,customer first,integrity-based",which are in accordance with the "integrity,pragmatic,pioneering,innovative" spirit of enterprise,so as to meet the needs of users with first-class service.
Warmly welcome friends from all walks of life to review,cooperate and create brilliance together!
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production The Company`s Main Products:
190 series gas engine parts,diesel engine parts,oil mud pump,turbocharger,marine diesel engine.
190 series diesel/gas engine and generator,marine diesel engine,coal gas generator.
190 series engine overhaul and maintenance.
OEM gas engine and oil engine.
The operation and maintenance of power station.
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
Quality Concept:
Quality is the starting point for value,brand and dignity.Quality must meet standards,meet demand,and satisfy customers."Quality first,reputation first."is the company`s unremitting pursuit!
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production Overhaul Cases:
After nearly ten years of exploration and accumulation, the company has formed a system of after-sales service system and complete technical support. At present, the company's maintenance service business has been extended to home and abroad.
Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production Small Steel Material 20MW Industrial Tail Gas Generator for Sustainable and Production
