Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Specifications
Shank Type :
smooth
Head Style :
Flat
Place of Origin :
Chongqing, China
Brand Name :
OEM
Model Number :
Insulation nail
Type :
Insulation nails
Material :
Steel+plastic, #60 Steel
Head Diameter :
60mm
Standard :
ISO
Name :
Concrete shooting nails
Steel nail Length :
42mm-62mm
Shank Diameter :
3.7mm
Surface treatment :
Electro Galvanized
Packing :
1000pcs/bag
Application :
Building Construction Material Fixing
Delivery time :
10-15days
Plastic Dia. :
50mm,60mm
Payment term :
30%TT Advance + 70% Balance
Packaging Details :
We usually pack them in toolkits first, then in cartons, or according to your requirements.
Port :
Shanghai,Guangzhou
Supply Ability :
5000000 Ton/Tons per Year
MOQ :
1000 pieces
Price :
$0.11/pieces 1000-9999 pieces
Description
Production Description
Material
HDPE
Color
White,grey,green, blue, red, etc
Washer diameter
50mm,60mm
Length
30mm~200mm
Nails Length
42mm,52mm, 62mm or as you need
Nails Diameter
3.7mm, 4.0mm
Application
Widely used for slab heating, enhence the wall of constrction, and for sound insulation
Customized
Support customization
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Insulation nails with plastic washer

Insulation fasteners for fixing mineral wool and EPS boards on soft to tough concrete, masonry and steel

Application: Insulation behind curtain walls, Insulation in ceilings, Basement/foundation moisture barrier

Insulation material: Mineral wool, Soft board (e.g. EPS)

Base materials: Concrete (soft), Concrete (tough), Concrete (uncracked), Steel, Masonry (solid limestone brick)
Specification
Insulation Plastic Length
Steel Nail Size
Color
Packing (PC/CTN)
30mm
3.7*42mm
White / Black/Grey
1000
40mm
3.7*42mm
White / Black/Grey
1000
50mm
3.7/4.0*52/62mm
White / Black/Grey
1000
60mm
3.7/4.0*52/62mm
White / Black/Grey
1000
70mm
3.7/4.0*52/62mm
White / Black/Grey
1000
80mm
3.7/4.0*52/62mm
White / Black/Grey
1000
90mm
3.7/4.0*52/62mm
White / Black/Grey
1000
100mm
3.7/4.0*52/62mm
White / Black/Grey
1000
110mm
3.7/4.0*52/62mm
White / Black/Grey
500
120mm
3.7/4.0*52/62mm
White / Black/Grey
500
130mm
3.7/4.0*52/62mm
White / Black/Grey
500
140mm
3.7/4.0*52/62mm
White / Black/Grey
500
150mm
3.7/4.0*52/62mm
White / Black/Grey
500
160mm
3.7/4.0*52/62mm
White / Black/Grey
500
170mm
3.7/4.0*52/62mm
White / Black/Grey
500
180mm
3.7/4.0*52/62mm
White / Black/Grey
500
190mm
3.7/4.0*52/62mm
White / Black/Grey
500
200mm
3.7/4.0*52/62mm
White / Black/Grey
500
Details Images
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Quality Raw Materials
Using high-quality HDPE material + galvanized steel screws as raw materials, it is guaranteed to be a new environmentally friendly
material used for the first time, high-quality and durable, and more assured to use.
Strong And Durable
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Energy Efficient
Galvanized steel nails solve the corrosion problem very well, have good durability, good heat transfer performance of the raw
material package, no cold bridge in winter, high efficiency and energy saving.
Various Specifications
Various specifications and complete varieties to meet your various customized needs.
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Product Testing
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer

The design of the surface of the disk has different effects; The quality of the plastic disk surface and the length and wire diameter of the inner thimble of the insulation nail will be tested. Finally, including the gun effect test will be strictly processed, as well as the number of nails that the matching nail gun can achieve and the hardness of the cement wall in the penetration test.
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Packing and Delivery
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer

Below 100 mm: 100 pieces/bag, 1000 pieces/carton;
Greater than 100 mm and less than 200 mm, 100 pieces/bag, 500 pieces/carton

Construction concrete wall heat insulation nails gas pins : bag or 50 pcs/bag. 1000 pcs/carton or 500 pcs/carton.
Our Factory
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer

Chongqing Liyufujie Trading Co,LTD

Established in 2013, Liyufujie professionally supply power actuated guns, gas nail guns and their accessories ( nails, powder loads, fuel cells) worldwide. A team of engineers engaged in this field for 8-25 years. A team of sales have good knowledge of products and high level of foreign language to give you good service. We exported our products to more than 20 countries.In China,
we have more than 20 shops in the big construction market, all of the below listed items are on sale.
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
Building Construction Material Fixing Steel Insulation Nails with Plastic Washer
FAQ
Q1: Where are your Factory?
A: We are located in Chongqing,China.

Q2: Are you trading company or manufacturer ?
A: We are a professional fastener manufacturer.

Q3:Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q4: What payment terms do you accept ?
A: At least 30% TT deposite,the remain balance paid before loading in our factory.

Q5: What's your MOQ? And how does your delivery?
A: MOQ is 10,000pcs in usual. But if your order cannot reach this limit,also want to purchase our products. Don't worry, We also accept sample orders, if the producing is not too tight.

Q6:What’s your Delivery Time?
 A: Generally it is 5-15 days，we have 10-lines production machine who is producing insulation fastener. And about 40,000 pieces production can be produced for a machine-line per day. So we can guarantee the delivery time very fast.

Q7:Can you produce according to customers' design?
A:Sure, we are professional manufacturer, OEM and ODM are both welcome. We'll offer you the quotation as soon as possible once receive your inquiry,so don't hesitate to contact us. We can produce the product under your brand name, also the size can be changed as your requirement.
