Microwave Horn Antenna For High Gain And Wide Frequency Range 5.0-7.0ghz
Microwave Horn Antenna For High Gain And Wide Frequency Range 5.0-7.0ghz
Specifications
Brand Name :
Famous
Model Number :
Horn Antenna
Certification :
CE，ISO9001
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T ， L/C
Packaging Details :
Standard export packaging/customizable packaging
Name :
Symmetrical Horn Antenna
Diameter of Mounting Pole :
Φ51~Φ114 mm
Antenna Connection :
Waveguide (special made by Dongguan Famous Precision) or SMA
Net Weight :
2.5kgs/5.5Ib
Material :
UV stabilized PC, aluminum alloy
Wind survivability :
200 km/h
Wind loading :
200 km/h
Mechanical adjustment: :
±25° elevation, ±25° azimuth
Pole compatibility :
Ø40 to 60 mm
Weatherproofing :
IP55
Description

Microwave Horn Antenna for High Gain and Wide Frequency Range 5.0-7.0GHz

  • Wideband Performance: The Symmetrical Horn Antenna can provide wideband performance, meaning it can operate across multiple frequency bands without frequent adjustments or antenna replacements.
  • High Gain: This type of antenna typically has high gain, making it useful for long-distance signal transmission or when strong signal reception is needed.
  • Radiation Pattern: The radiation pattern of the Symmetrical Horn Antenna is symmetrical and precise, allowing it to provide accurate signal coverage in specific areas, suitable for applications that require directional transmission or reception.
  • Interference Resistance: Due to its special design, this antenna has strong interference resistance, effectively handling interference signals in the surrounding environment.
  • Weather Adaptability: Symmetrical Horn Antennas are designed for outdoor applications and can maintain stable performance in different weather conditions such as high temperatures, low temperatures, humidity, or dryness.
  • Mechanical Structural Advantages: These antennas typically have a simple mechanical structure, making them easy to install and maintain, which is beneficial for large-scale deployments or scenarios that require frequent adjustments.

Efficient PtMP horn antenna:

  • Wide frequency range 5.0-7.0GHz;
  • High isolation: 30° ;
  • With fast and easy installation waveguide;
  • High Gain;


Electrical performance:

Frequency Range (GHz)

 Gain (dBi) Azimuth Beam Width -3dB Elevation Beam Width -3dB Azimuth Beam Width -6dB Elevation Beam Width -6dB Front/Back Ratio(dB) VSWR Polarization
30° 5.0-7.0 18

H21°

V21°

H21°

V21°

H30°

V30°

H30°

V30°

 37 ≤1.8 Dual-Linear
40° 5.0-7.0 16

H27°

V27°

H27°

V27

H40°

V40°

H40°

V40°

 35 ≤1.8 Dual-Linear
50° 5.0-7.0 14

H33°

V33°

H33°

V33°

H50°

V50°

H50°

V50°

 33 ≤1.8 Dual-Linear
60° 5.0-7.0 13

H41°

V41°

H41°

V41°

H60°

V60°

H60°

V60°

 32 ≤1.8 Dual-Linear
70° 5.0-7.0 11

H50°

V50°

H50°

V50°

H70°

V70°

H70°

V70°

 30 ≤1.8 Dual-Linear
80° 5.0-7.0 10

H60°

V60°

H60°

V60°

H80°

V80°

H80°

V80°

 29 ≤1.8 Dual-Linear
90° 5.0-7.0 9

H67°

V67°

H67°

V67°

H90°

V90°

H90°

V90°

 28 ≤1.8 Dual-Linear
Antenna Connection Waveguide (special made by Dongguan Famous Precision) or SMA
Net Weight 2.5kgs/5.5Ib
Material UV stabilized PC, aluminum alloy
Wind survivability 200 km/h
Wind loading 200 km/h
Mounting Mechanical adjustment: ±25° elevation, ±25° azimuth
Pole compatibility: Ø40 to 60 mm
Weatherproofing IP55
