10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
10KV SF6 Gas Insulated Ring Main Unit Switchgear Medium Voltage 630A To 3150A Current
Specifications
Brand Name :
Dong Sheng Yuan
Model Number :
10KV SF6 Gas Insulated Ring Main Unit
Place of Origin :
China
Installation :
Indoor/Outdoor
Modular Design :
Yes
Current :
Up to 4000 A
Compact Design :
3150A
Temperature Range :
-40°C to +55°C
Insulation :
SF6 gas
Type :
Gas Insulated Switchgear
Safety :
High
Maintenance :
Low
Life Expectancy :
Over 30 years
Delivery Time :
T+30
Payment Terms :
TT
Description

SF6 Gas Insulated Ring Main Unit


Dongshengyuan will provide you with a whole solution for SF6 gas-insulated switchgear.

The range of voltage rating is from 12kV, 24kV to 36kV.

Current rating from 630A to 3150A.

Short circuit current rating from 16kA to 40kA.

RMR RMU is a secondary switchgear, which is rated up to 40.5kV,1250A,25kA

RGIS C-GIS is a primary switchgear, which is rated up to 40.5kV,3150A,40kA.

RMC M-GIS is an economic type GIS switchgear for connection from RMU to C-GIS. The rating is up to 40.5kV,1250A,31.5kA.

---------------------------------------------------------------------

What is RMU, Ring Main Unit

Ring Main Unit (RMU) is a totally sealed unit with SF6 gas or other insulation material. DSY's RMU is a gas-insulated compact switchgear unit.

A ring main unit or RMU is combined with a minimum of three ways. The primary switching devices can be either switch disconnectors or fused switch disconnectors, or circuit breakers (VCB or GCB).

Normally, a primary circuit breaker is the switching device, which can be a vacuum circuit breaker or a gas circuit breaker, etc. It is always equipped with a protective relay; it is a very basic self-powered type or a more advanced one with communication capabilities.
The rated voltage and current ranges for RMUs typically reach up to 40.5 kV and 630 A, respectively.

Different combinations of LD requests, pls contact us.
