10A 220V DC Circuit Breaker Accessories 3NO / 2NO1NC Auxiliary Switch For MV Switchgear
10A 220V DC Circuit Breaker Accessories 3NO / 2NO1NC Auxiliary Switch For MV Switchgear
Specifications
Name :
Circuit Breaker Accessories
Rated voltage :
DC220 | AC380
Rated current :
10A | 15A
Insulation voltage :
660V
Electric life :
20000 time
Mechanical life :
30000 time
Description

Circuit Breaker GDF Series Auxiliary Switches


GDF Series Auxiliary Switches GDF-3

1. Product Introduction
This product is widely used in middle-positioned high voltage swichgear's handcart, vacuum contactor,
vacuum load switch, and other high voltage switch equipment, used as indication or interlock in connecting,
breaking, tripping, signal,etc.

2. Specification
1) 3 pairs of contacts, 4 different structure models for choice: 3NO, 2NO1NC, 1NO2NC,3NC
2) Type(Ⅰ): Push rod with connecting piece (L)
Type (Ⅱ):Push rod with buffering piece (H)

3.Basic Technical Data

Rated voltage V

DC220

AC380

Rated current

10A

15A

Rated breaking current

-3 e=22

COS Φ=0.4

Insulation voltage

660V

Electric life

20000 time (open/close)

Mechanical life

30000 time (open/close)

Travel distance of push rod

6.5-7mm









4. Outline Dimensions
