Rigid PCBs for Medical Equipment

Medical PCBs (Printed Circuit Boards) are specialized circuit boards designed and manufactured to meet the stringent requirements of medical devices. They are essential components in everything from simple diagnostic tools to complex life-support systems. Due to the critical nature of their applications, these PCBs must adhere to extremely high standards of reliability, precision, and quality.

Our are meticulously engineered to meet the rigorous demands of the healthcare industry. These boards are manufactured with advanced materials and precision techniques, ensuring exceptional reliability and long-term performance for critical medical applications. Featuring high-density interconnect (HDI) technology, multi-layer designs, and biocompatible finishes, our PCBs are ideal for devices requiring both miniaturization and flawless functionality. Each board undergoes stringent quality control and testing, including IPC Class III standards, to guarantee the highest level of safety and performance. Trust our medical PCBs to be the reliable foundation for your life-saving and diagnostic equipment."

Application Scenarios:

• Diagnostic Imaging: MRI, CT scanners, and ultrasound machines use complex PCBs to process and display high-resolution images.

• Implantable Devices: Pacemakers, defibrillators, and neurostimulators require ultra-compact, highly reliable PCBs that can operate flawlessly within the human body.

• Surgical Equipment: Robotic surgery systems, endoscopes, and electrosurgical tools rely on PCBs for precise control and communication.

• Patient Monitoring: Heart rate monitors, blood glucose meters, and pulse oximeters use PCBs to collect and analyze vital signs.

• Therapeutic Devices: Infusion pumps, dialysis machines, and ventilators depend on robust PCBs for accurate and continuous operation.

Production Process:

Design Review: Strict DFM/DFR review of Gerber files to ensure compliance with medical standards.

Inner Layer Fabrication: Fabricate inner layer circuits.

Lamination: Precise alignment and lamination using high-performance materials (e.g., high-TG FR-4).

Interconnection: Drilling and plating to establish reliable interlayer connections.

Outer Layer & Finishing: Apply outer circuit pattern, solder mask, and silkscreen.

Testing & QC:Rigorous AOI inspection, electrical testing (Flying Probe), and reliability testing before packaging.

Compliance: Full adherence to ISO 13485 standards to ensure high reliability for critical medical devices.
