Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Specifications
Brand Name :
Xingqiang
Model Number :
As Per Customer's Model
Place Of Origin :
China
Certification :
ISO 9001 / RoHS /UL / IATF 16949 (automotive)
MOQ :
Sample,1 Pc(5 Square Meters)
Price :
Based on BOM List
Packaging Details :
As Customer Requirements
Payment Terms :
T/T,Western Union
Supply Ability :
100000㎡/Month
Delivery Time :
NA
PCB Type :
Custom PCBA
Min. Hole Size :
0.1mm
Min Line Spacing :
3Mil
Material :
FR-4
Copper Overall :
0.5-5oz
Quotation Request :
BOM List
Test :
100% E-Test
Pcb Layer :
1-30 layers
Dimension :
Customized
Surface Finish :
HASL, ENIG, OSP
Pcb Standard :
IPC-A-610 E Class II
Solder Mask :
Red,Green,Yellow,White,Black,Blue
Description
Custom PCB Assembly with White Solder Mask Color and 0.1mm Min. Hole Size
High Temperature Resistant Assembly Circuit Board

PCBA, short for Printed Circuit Board Assembly, refers to the process of mounting and soldering electronic components—such as resistors, capacitors, chips, and connectors—onto a printed circuit board (PCB). This assembly transforms a bare PCB into a functional electronic unit, enabling devices like smartphones, computers, and home appliances to operate efficiently. Essentially, it bridges design and final product manufacturing in electronics.

Main Features
  • Product Name: Custom PCB Assembly
  • Solder Mask Color: Green, Red, Blue, Black, White
  • Surface Finish: HASL, ENIG, OSP
  • PCB Standard: IPC-A-610 E Class II
  • Material: FR-4
  • Min. Hole Size: 0.1mm
Major PCBA Manufacturing Challenges
Challenge Description
Miniaturization Handling and placing extremely small (e.g., 01005) or complex (e.g., BGA) components requires ultra-high precision and specialized X-Ray Inspection (AXI).
Solder Quality Controlling solder paste application and the reflow temperature profile to prevent defects like bridging (shorts), tombstoning, and weak joints.
Thermal Management Preventing component overheating by effectively dissipating heat from the densely packed components and managing thermal stress during soldering.
Supply Chain Dealing with component shortages, quality and reliability risks from non-qualified components, and the constant need to manage component obsolescence (EOL).
DFM Issues Ensuring the design adheres to manufacturing rules (e.g., sufficient clearance, proper test points) to avoid defects and low yield loss.
Manufacturing Excellence
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Factory Showcase
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
PCB Quality Testing
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Certificates and Honors
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Quality Certifications
Custom PCB Assembly with White Solder Mask, 0.1mm Min. Hole Size, and FR-4 Material
Production Capabilities
