ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
Specifications
Model Number :
Minimeta
Accuracy :
≤±2-5%FS
Explosion-proof certification :
IECEx, ATEX
Price :
Negotiable
Gas Detected :
cl2
Supply Ability :
3000 pieces per month
Detection Principle :
Diffusion
Certification :
ATEX/EMC/IECEX
Power supply mode: :
3.6V dry battery (non-rechargeable and replaceable)
Payment Terms :
T/T,Western Union
Dimensions :
90mm*60mm*33mm (length*width*thickness)
Resolution :
0.01ppm
MOQ :
1
Delivery Time :
3 work days
Weight (With Clip) :
125g
Working humidity (non-condensing) :
0-95%RH
Working air pressure :
86 to 106kpa
Alarm type :
Low alarm, high alarm, STEL, TWA, low battery optional calibration due and bump test due
Packaging Details :
Carton
Measure range :
0-10ppm 0-50ppm
Display :
Gas name, battery power, concentration unit, measured value
Brand Name :
SAFEGAS
Alarm mode :
Sound, light, vibration alarm
Protection class :
IP66/68
Place of Origin :
China
Response time(T90) :
15 to 30s
Working temperature :
-20℃ to 55℃
Principle :
Electrochemical principle
Description
ATEX Certified Portable Single Toxic Gas Detector For Chlorine Industrial Wastewater Plant Use
Product Overview

The MiniMeta Portable CL2 Gas Detector is a high-precision portable gas detector designed for chlorine detection using diffusion detection principle, specifically engineered for industrial safety applications in wastewater treatment plants and similar environments.

This IECEX/ATEX/EMC certified single-gas detector can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection, offering a low-cost, long-term ownership gas monitoring system.

Key Features
  • IP68 water- and dust-resistant case
  • Low power consumption with 2 years standby time - no battery charging or calibration needed
  • Optional single/multi unit docking station for daily bump test and calibration
  • Event and data logging function
  • Self-test function for improved safety through automatic self-testing
  • Small size, lightweight design with back clip for easy carrying
  • 95db@30cm buzzer alarm, 2 high-bright red LED light alarm and vibration alarm
  • Real time value, TWA, STEL, MAX, MIN multiple numerical display
Applications
  • Sewage treatment plant chlorine leak inspection
  • Chemical chlorination workshop toxic gas monitoring
  • Swimming pool disinfection room gas concentration testing
  • Pesticide manufacturing workshop harmful gas early warning
  • Textile bleaching factory workplace safety detection
  • Municipal water disinfection station chlorine leakage alarm
  • And more industrial applications
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
Technical Parameters
Parameter Specification
Detect gas CL2 (Chlorine)
Sensor type Electrochemical
Sampling method Diffusion
Measure range 0-10ppm / 0-50ppm
Resolution 0.01ppm
Precision ≤± 3% F.S.
Response Time ≤30s (T90)
Display Gas name, concentration unit, measured value, battery level
Alarm mode Sound, light, vibration alarm
Alarm type Low alarm, high alarm, STEL, TWA, low battery
Operating language Chinese/English
Size 90×60×33mm
Weight 125g
Working Temperature -20ºC to 50ºC
Working Humidity 0-95%RH
Working air pressure 86-106kpa
Company Advantages
  • R&D team experience: over 25 years
  • Company certifications: ISO9001, ISO45001
  • Product certifications: IECEx, ATEX, CE
  • Delivery time: 5-7 days
  • Annual capacity: 80,000 units
  • Professional 7×24 hours customer service
Manufacturer Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.

Product Line
Portable Detectors:
  • Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000, SKY1000, MAXMETA
Fixed Systems:
  • YT-95H, YT-98H, YT-96H, SG100, SG200
Controllers:
  • YT-1100H, YT-1600H, YT-1800H
Particle Counters:
  • AQD5000, SKY6000-PM, SKY2000-PM
