Specifications
Brand Name :
KLSK
Model Number :
WT-602
Certification :
CE
Place of Origin :
Jiangsu, China
MOQ :
1PC
Price :
$1,200.00/pieces
Packaging Details :
Standard exporting package-Carton box
Stock :
1PC
Warranty :
1 years
Type :
Dust analyzer
Customized support :
OEM
Working wavelength :
650nm
Product name :
Dust Monitoring Equipment
Gas analyzer principle :
Scattered light backward
Application :
Online Stack Dust Monitor
Power :
24VDC+/-10%
Work temperature :
-40 ℃-+50 ℃
Measure Range :
0~200mg/m3, 0~10g/m3
Signal output :
(4-20) mA
Response time :
≤ 10s
Description
WT602 Series Continuous Gas Monitoring System - Industrial Waste Gas and Smoke Dust Meter
Working Principle
WT602B series products utilize laser backscatter technology to measure flue dust concentration. The embedded high-stability laser signal source passes through the flue and irradiates smoke particles. The irradiated particles reflect the laser signal, with reflected signal intensity varying proportionally with smoke concentration. Flue dust concentration is calculated using specialized algorithms.
WT602 Dust Analyzer for Process Control and Pollution Source Monitoring
Technical Specifications
Parameter WT602 Specification
Principle Laser backscatter
Working wavelength 650nm
Zero drift ±2%F.S./24h
Range drift ±2%F.S./24h
Indication error ±15%
Response time ≤ 10s
Diameter of flue (1-15)m
Operating temperature (-40~+65) ºC
Flue temperature <200ºC
Flue pressure <1Kpa
Signal output (4-20) mA
Power supply DC 24V ± 10%
WT602 Dust Analyzer for Process Control and Pollution Source Monitoring
Product Catalog
WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring
Company Information
WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring WT602 Dust Analyzer for Process Control and Pollution Source Monitoring
Frequently Asked Questions
Are you a trading company or manufacturer?
We are a manufacturer.
What about the payment method?
T/T, Paypal, Western Union, L/C are available.
Does your company accept customization?
We provide customizing services for customers.
What about the Shipment?
We select appropriate transportation methods based on product weight, typically arranging shipment by air express such as DHL, FEDEX, TNT, or UPS.
What about after-sale service?
12 months warranty for all products.
