36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments
36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments
Specifications
Brand Name :
MingTong
Model Number :
GYTS
Certification :
ISO
Place of Origin :
Dong Guan China
Price :
500-5000RNB/KM
Payment Terms :
L/C, T/T
Supply Ability :
200km/Day
Delivery Time :
It depends on the actual situation.
MOQ :
20km
Packaging Details :
Wooden scroll + cardboard box / Wooden scroll + wooden board
Loose Tube Material: :
PBT Or Jelly
Outer Sheath Material: :
PE
Single Armour Material :
Corrugated Aluminium Tape
Outer Sheath Color :
Black
Waterblocking Material :
Water Blocking Tape Or Filling Compound
Messenger Material :
Steel Wires
Highlight :
96 Core Armored Fiber Optic Cable, GYTS Armored Fiber Optic Cable, 72 core shielded fiber optic cable
Name :
Armored Optical Cable
Description
Product Description

36/72/96 Core Armoured Duct Fiber Optical Fiber Cable GYTS

36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments


2-288 Core Optical Fiber Cable including outdoor 2-288 Core Optical Fiber Cable, indoor 2-288 Core Optical Fiber Cable, ftth 2-288 Core Optical Fiber Cable.
2-288 Core Optical Fiber Cable Certificate including REACH,ISO9001, SGS, RoHS. 2-288 Core Optical Fiber Cable capacibility 300km/day. We have varity of 2-288 Core Optical Fiber Cable modules, accept custom and supply OEM, ODM services. We have strong sales team, 24 hours supply consult and quotation for you.

36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments

GYTS optic fiber cable Technology Specification

Cable Count Out sheath Weight Minimum allowable Tensile Strength minimum allowable Crush Load Minimum Bending Radius Storage
Diameter (N) (N/100mm) (MM) temperature
(MM) (KG) short term long term short term long term short term long term (°C)
2-60 9.8 116 1500 600 1000 300 20D 10D -20+60
62-72 10.5 146 1500 600 1000 300 20D 10D -20+60
74-96 12.8 174 1500 600 1000 300 20D 10D -20+60
98-120 14.5 209 1500 600 1000 300 20D 10D -20+60
122-216 15.5 271 1500 600 1000 300 20D 10D -20+60
GYTS optic fiber cable Optical Characteristics: :
Fiber Sort Multimode G.651 A1a:50/125 Graded-index fiber
A1b:62.5/125
Singlemode G.652(A,B,C) B1.1:Conventional fiber
G.652D B2: Zero dispersion shifted
G.655 B1.2 :Cut-off wavelength shifted
G.657(A1,A2 ,B3) B4: Main technical data for positive
dispersion shifted single-mode fiber


GYTS Fiber Optic Cable Details

GYTS 2-288 Core Optical Fiber Cable Competitive Advantages
1.OEM fiber optic cable manufacturer
2. Fiber brand : YOFC, CORNING,FUJIKURA
3.Quality certification :ISO9001.ROSH.REACH
4.Cooperate with Vietnam telecom, Thai telecom, Singapore telecom, Dubai telecom and other big projects
5.Tw-scie known as the fiber optic cable manufacturer for the excellent products quality, competitive prices , fast delivery and good service.

Shipping & Packing &Payment &FAQ

· All available shipping ways could be applied, by courier, air or sea.
· Appointed shipping company or our own forwarders all could be used in shipment.
· Full-way tracking the cargos for you before the goods arrive.

36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments

36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments

36 72 96 Core Armored Fiber Optic Cable For Connecting Communication Equipments
