Baofeng T20D UHF 400-470MHz Digital Walkie Talkie 2W Handheld Radio

Specifications

Model Number :

T20D

MOQ :

Price :

Payment Terms :

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Packaging Details :

25*20*10cm Piece/Pieces

Delivery Time :

7-15 work day

Supply Ability :

100 Piece/Pieces 7days

Description

Baofeng T20D UHF 400-470MHz Digital Walkie Talkie 2W Handheld Radio

Specifications

Main Features
 * UHF400-480MHz Transceiver
* Output power: Max 2W
* Channel spacing: 12.5 KHz/25.0 KHz
* Analog/ Encrypted channel Scan
* Vocal tuning
* Battery save
* Channel Monitor
* Analog Squelch
* 51 CTCSS tones and 210 DCS codes
* TOT (Time out timer)
* 2pin Kenwood accessory jack
* Type-C charge
Transmitter :
Output Power 0.5W/2W
Modulation Mode(W/N Band) 16KΦF3E/11KΦF3E
Maximum Frequency Deviation (W/N Band) ≤5KHz / ≤2.5KHz
Spurious Power ≤7.5 µW
Adjacent channel power ≤-65dB/≤-60dB
Audio Distortion <5 %
SNR ≥-45dB/≥-40dB
CTSCC/DCS Frequency Deviation(W/N Band) 0.7±0.1KHz (W), 0.4±0.1KHz (N)
Modulation Sensitivity 8-12mV
Transmitting Current ≤1000mA

Receiver:
Sensitivity <0.25 µ V (12dB SINAD)
Audio Power 1 W
Inter modulation Interference Resistance ≥65dB (W), ≥60dB (N)
Adjacent channel Selectivity (W/N Band) ≥65dB (W), ≥55dB (N)
Audio Distortion 5 %
Receiving Current ≤ 380m A
