Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

Specifications

Brand Name :

BUGAO

Model Number :

608

Place Of Origin :

Ningbo, China

Certification :

ISO9001:2015

MOQ :

3000 Pcs

Price :

Negotiable

Packaging Details :

Single Packing, Industrial Packing/Tube Packing

Delivery Time :

20 -30 Days

Payment Terms :

30% Deposit,70% Before Shipment

Supply Ability :

30,000,000

Bearing Name :

608 Ball Bearings

Precision Rating :

ABEC-1, ABEC-3, ABEC-5, ABEC-7

Contact Angle :

0 Degree

Seal Type :

Open, ZZ, RZ, 2RS

Bearing Type :

Single Row Deep Groove Ball

Series :

6000 Series Bearing

Noise & Vibration :

Z1V1, Z2V2, Z3V3, Z4V4

Number Of Rows :

Single Row

Stock :

Rich

Customization :

Customization Welcomed

Description

Customization 6000 Series Bearing For Z4V4 Performance Low Noise Vibration Control In Stainless Steel Material

Product Description:
The Z4V4 608 Precision Ball Bearing is a custom-engineered, high-performance solution designed for applications demanding exceptional accuracy, durability, and corrosion resistance. Manufactured from premium stainless steel (AISI 440C or 304/316 for food-grade options) and meeting ABEC-5 tolerance standards, this bearing ensures smooth operation, minimal vibration, and extended service life even in high-speed or harsh environments. The Z4V4 clearance rating provides optimal internal fit for reduced friction, while optional double seals (2RS) or shields (ZZ) protect against contamin.

Dimensional Diagram (608 Bearing Standard Sizes)

Inner Diameter (d): 8 mm

Outer Diameter (D): 22 mm

Width (B): 7 mm

Material: Stainless Steel (AISI 440C/304/316)

Clearance: Z4V4 (Customizable to C3/C4 if needed)

Sealing: Optional ZZ (metal shields) or 2RS (rubber seals)

Key Advantages & Applications

Performance Benefits:

ABEC-5 Precision: Tight tolerances for low noise, high-speed rotation (up to 30,000 RPM with grease lubrication).
Stainless Steel Construction: Resists rust, chemicals, and moisture—ideal for food processing, marine, or medical equipment.
Z4V4 Clearance: Optimized internal fit reduces friction and heat buildup vs. standard bearings.
Customizable: Available with shields, seals, or open designs, and special greases (food-grade, high-temperature).

Typical Applications:

High-Speed Machinery: Dental drills, CNC spindles, robotics.

Corrosive Environments: Marine equipment, chemical pumps, washdown areas.

Food & Medical: Conveyors, mixers, pharmaceutical devices (316 stainless steel option).

Precision Instruments: Optical devices, measuring tools, drones.

Request a Quote: Specify your required quantity, sealing type, and material grade for a tailored solution.

Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

Technical Parameters of 6000 Series Deep Groove Ball Bearing:

Basic Bearing No.	Bore d		Outer Diameter D		Width W		Radius r		Basic Load Rating KN		Maximum Run out Speed		Weight Kg/pc
									Basic Load Rating KN		Maximum Run out Speed
									Dynamic	Static	Grease	Oil
									Dynamic	Static	Grease	Oil
	mm	inch	mm	inch	mm	inch	mm	inch	C	C_O	r/min	r/min
604	4	0.1575	12	0.4724	4	0.1575	0.2	0.008	0.97	0.36	43000	51000	0.002
605	5	0.1969	14	0.5512	5	0.1969	0.2	0.008	1.33	0.505	39000	46000	0.0035
606	6	0.2362	17	0.6693	6	0.2362	0.3	0.012	2.24	0.91	28000	36000	0.008
607	7	0.2756	19	0.7480	6	0.2362	0.3	0.012	2.24	0.91	28000	36000	0.008
608	8	0.3149	22	0.8661	7	0.2756	0.3	0.012	3.35	1.4	26000	34000	0.012
609	9	0.3543	24	0.9449	7	0.2756	0.3	0.012	3.4	1.45	22000	30000	0.014
6000	10	0.3937	26	1.0236	8	0.3150	0.3	0.012	4.55	1.96	20000	28000	0.019
6001	12	0.4724	28	1.1024	8	0.3150	0.3	0.012	5.1	2.39	19000	26000	0.021
6002	15	0.5906	32	1.2598	9	0.3543	0.3	0.012	5.6	2.84	18000	24000	0.03
6003	17	0.6693	35	1.3780	10	0.3937	0.3	0.012	6.8	3.35	17000	22000	0.039
6004	20	0.7874	42	1.6535	12	0.4724	0.6	0.024	9.4	5.05	15000	19000	0.069
6005	25	0.9843	47	1.8504	12	0.4724	0.6	0.024	10.1	5.85	13000	17000	0.08
6006	30	1.1811	55	2.1654	13	0.5118	1.0	0.039	13.2	8.3	12000	15000	0.116
6007	35	1.3780	62	2.4409	14	0.5512	1.0	0.039	16	10.3	10000	13000	0.155
6008	40	1.5748	68	2.6772	15	0.5906	1.0	0.039	16.8	11.5	8000	11000	0.185
6009	45	1.7717	75	2.9528	16	0.6299	1.0	0.039	21	15.1	7200	9000	0.231
6010	50	1.9685	80	3.1496	16	0.6299	1.0	0.039	21.8	16.6	6400	7800	0.25
6011	55	2.1654	90	3.5433	18	0.7087	1.1	0.043	28.3	21.2	5700	7000	0.362
6012	60	2.3622	95	3.7402	18	0.7087	1.1	0.043	29.5	23.2	5000	6300	0.385
6013	65	2.9551	100	3.9370	18	0.7087	1.1	0.043	31.9	25	4800	6100	0.44
6014	70	2.7559	110	4.3307	20	0.7874	1.1	0.043	39.7	31	4600	5800	0.6
6015	75	2.9528	115	4.5276	20	0.7874	1.1	0.043	41.6	33.5	4400	5600	0.64

Applications:

Its single row design and steel cage type make it a robust choice for applications requiring high load capacity and smooth operation. The seal options of open, ZZ, RZ, and 2RS provide flexibility for different operating conditions.

Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

Customization Welcomed:

We can printing your brand (logo,artwork)on the shield or laser engraving your brand on the shield.
We can custom your packaging according to your design.
All copyright owned by clients and we promised don't disclose any information.

Packing and Shipping:

The deep groove ball bearings will be securely packaged individually, or tube packing or packed as customization packing
Shipping method is negotiable.

Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

ABEC-1 Tolerance Class ABEC-1 (P0)

Inner Ring									Tolerance in um/s
d mm		Δdmp		9	Vdp²)0,1 Diameter Series	2,3,4	Vdmp	Kia	ΔBs		Vbs
d mm		Δdmp		9	Vdp²)0,1 Diameter Series	2,3,4	Vdmp	Kia	ΔBs		Vbs
over	including	high	low	max			max	max	high	low	max
1)0.6	2.5	0	-8	10	8	6	6	10	0	-40	12
2.5	10	0	-8	10	8	6	6	10	0	-120	15
10	18	0	-8	10	8	6	6	10	0	-120	20
18	30	0	-10	13	10	8	8	13	0	-120	20
30	50	0	-12	15	12	9	9	15	0	-120	20
50	80	0	-15	19	19	11	11	20	0	-150	25

Outer Ring									Tolerance in um/s
D mm		Δdmp		VDp²)⁴)Open Bearings Diameter Series			Capped Bearings²)³)	Vdmp	Kia	ΔBs		Vbs
D mm		Δdmp		9	0,1	2,3,4	2,3,4	Vdmp	Kia	ΔBs		Vbs
over	including	high	low	max				max	max	high	low	max
1)2.5	6	0	-8	10	8	6	10	6	15	Identical to ΔBs and VBs of inner ring of same bearing
6	18	0	-8	10	8	6	10	6	15
18	30	0	-9	12	9	7	12	7	15
30	50	0	-11	14	11	8	16	8	20
50	80	0	-13	16	13	10	20	10	25
80	120	0	-15	19	19	11	26	11	35
120	150	0	-18	23	23	14	30	14	40

ABEC-3 Tolerance Class ABEC-3 (P6)

Inner Ring									Tolerance in um/s
d mm		Δdmp		9	Vdp²)0,1 Diameter Series	2,3,4	Vdmp	Kia	ΔBs		Vbs
d mm		Δdmp		9	Vdp²)0,1 Diameter Series	2,3,4	Vdmp	Kia	ΔBs		Vbs
over	including	high	low	max			max	max	high	low	max
11)0.6	2.5	0	-7	9	7	5	5	5	0	-40	12
2.5	10	0	-7	9	7	5	5	6	0	-120	15
10	18	0	-7	9	7	5	5	7	0	-120	20
18	30	0	-8	10	8	6	6	8	0	-120	20
30	50	0	-10	13	10	8	8	10	0	-120	20
50	80	0	-12	15	15	9	9	10	0	-150	25

Outer Ring									Tolerance in um/s
D mm		Δdmp		VDp²)⁴)Open Bearings Diameter Series			Capped Bearings²)³)	Vdmp	Kia	ΔBs		Vbs
D mm		Δdmp		9	0,1	2,3,4	2,3,4	Vdmp	Kia	ΔBs		Vbs
over	including	high	low	max				max	max	high	low	max
1)2.5	6	0	-7	9	7	5	9	5	8	Identical to ΔBs and VBs of inner ring of same bearing
6	18	0	-7	9	7	5	9	5	8
18	30	0	-8	10	8	6	10	6	9
30	50	0	-9	11	9	7	13	7	10
50	80	0	-11	14	11	8	16	8	13
80	120	0	-13	16	16	10	20	10	18
120	150	0	-15	19	19	11	25	11	20

ABEC-5 Tolerance Class ABEC-5 (P5)

Inner Ring									Tolerance in um/s
d mm		Δdmp		Vdp²)Diameter Series		Vdmp	Kia	Sd	Sis³⁾	ΔBs	Vbs
d mm		Δdmp		9	0,1,2,3,4	Vdmp	Kia	Sd	Sis³⁾	ΔBs	Vbs
over	including	high	low	max		3	max	max	max	High	Low	max
1)0.6	2.5	0	-5	5	4	3	4	7	7	0	-40	5
2.5	10	0	-5	5	4	3	4	7	7	0	-40	5
10	18	0	-5	5	4	3	4	7	7	0	-80	5
18	30	0	-6	6	5	3	4	8	8	0	-120	5
30	50	0	-8	8	6	4	5	8	8	0	-120	5
50	80	0	-9	9	7	5	5	8	8	0	-150	6

Outer Ring									Tolerance in um/s
D mm		Δdmp		Vdp²)Diameter Series		Vdmp	Kia	SD⁴⁾ SD1⁵⁾	Sea⁴⁾⁵⁾	ΔBs		Vbs
D mm		Δdmp		9	0,1,2,3,4	Vdmp	Kia	SD⁴⁾ SD1⁵⁾	Sea⁴⁾⁵⁾	ΔBs		Vbs
over	including	high	low	max			max	max	max	High	Low	max
1)2.5	6	0	-5	5	4	3	5	8	8			5
6	18	0	-5	5	4	3	5	8	8			5
18	30	0	-6	6	5	3	6	8	8			5
30	50	0	-7	7	5	4	7	8	8			5
50	80	0	-9	9	7	5	8	8	10			6
80	120	0	-10	10	8	5	10	9	11			8
120	150	0	-11	11	8	6	11	10	13			8

ABEC-7 Tolerance Class ABEC-7 (P4)

Inner Ring												Tolerance in um/s
d mm		Δdmp		Δds		Vdp²)Diameter Series		Vdmp	Kia	Sd	Sia	ΔBs		Vbs
d mm		Δdmp		Δds		7,8,9	1,7,2,3,4	Vdmp	Kia	Sd	Sia	ΔBs		Vbs
over	including	high	low	high	low	max		max	max	max	max	High	low	Low	max
1)0.6	2.5	0	-4	0	-4	4	3	2	2.5	3	3	0	-40	-40	2.5
2.5	10	0	-4	0	-4	4	3	2	2.5	3	3	0	-40	-40	2.5
10	18	0	-4	0	-4	4	3	2	2.5	3	3	0	-80	-80	2.5
18	30	0	-5	0	-5	5	4	2.5	3	4	4	0	-120	-120	2.5
30	50	0	-6	0	-5	6	4	3	4	4	4	0	-120	-120	3
50	80	0	-7	0	-5	7	5	3.5	4	5	5	0	-150	-150	4

Outer Ring												Tolerance in um/s
D mm		Δdmp		Δds		Vdp²)Diameter Series		Vdmp	Kia	Sd	Sia	ΔBs		Vbs
D mm		Δdmp		Δds		7,8,9	1,7,2,3,4	Vdmp	Kia	Sd	Sia	ΔBs		Vbs
over	including	high	low	high	low	max		max	max	max	max	High	low	max
1)2.5	6	0	-4	0	-4	4	3	2	3	4	5	Identical to ΔBs and VBs of inner ring of same bearing		2.5
6	18	0	-4	0	-4	4	3	2	3	4	5			2.5
18	30	0	-5	0	-5	5	4	2.5	4	4	5			2.5
30	50	0	-6	0	-6	6	5	3	5	4	5			2.5
50	80	0	-7	0	-7	7	5	3.5	5	4	5			3
80	120	0	-8	0	-8	8	6	4	6	5	6			4
120	150	0	-9	0	-9	9	7	5	7	5	7			5

Tolerance Data for Vibration of Single Bearing

D	V			V1			V2			V3			V4
mm	Low	Medium	High	Low	Medium	High	Low	Medium	High	Low	Medium	High	Low	Medium	High
3,4	80	44	44	60	35	32	48	26	22	31	16	15	28	10	10
5,6	110	72	60	74	48	40	58	36	30	35	21	18	32	11	11
7,8,9	130	96	80	92	66	54	72	48	40	44	28	24	38	12	12
10,12	160	120	100	120	80	70	90	60	50	55	35	30	45	14	15
15	210	150	120	150	100	85	110	78	60	65	46	35	52	18	18
17	210	150	120	150	100	85	110	78	60	65	46	35	52	25	25
20	260	190	150	180	125	100	130	100	75	80	60	45	60	25	25
22,25	260	190	150	180	125	100	130	100	75	80	60	45	60	30	32
28	260	190	150	180	125	100	130	100	75	80	60	45	60	35	40
30,32	300	240	190	200	150	130	150	120	100	90	75	60	70	35	40
35	300	240	190	200	150	130	150	120	100	90	75	60	70	42	45
40	360	300	260	240	180	160	180	150	130	110	90	80	82	50	50
45	360	300	260	240	180	160	180	150	130	110	90	80	82	60	60
50	420	320	320	280	200	200	210	160	160	125	100	100	95	70	70

Maximum Vibration Acceleration of Single Bearing

D	Diameter Series(0)				Diameter Series(2)					Diameter Series(3)
mm	Z	Z1	Z2	Z3	Z	Z1	Z2	Z3	Z4	Z	Z1	Z2	Z3	Z4
3	35	34	32	28	36	35	32	30	-	37	36	33	31	-
4	35	34	32	28	36	35	32	30	-	37	36	33	31	-
5	37	36	34	30	38	37	34	32	-	39	37	35	33	-
6	37	36	34	30	38	37	34	32	-	39	37	35	33	-
7	39	38	35	31	40	38	36	34	-	-	-	-	-	-
8	39	38	35	31	40	38	36	34	-	-	-	-	-	-
9	41	40	36	32	42	40	37	35	-	-	-	-	-	-
10	43	42	38	33	44	42	39	35	30	37	44	40	37	32
12	44	43	39	34	45	43	39	35	30	47	45	40	37	32
15	45	44	40	35	46	44	41	36	31	48	46	42	38	33
17	46	44	40	35	47	45	41	36	31	49	47	42	38	33
20	47	45	41	36	48	46	42	38	33	50	48	43	39	34
22	47	45	41	36	48	46	42	38	33	50	48	43	39	34
25	48	46	42	38	49	47	43	40	36	51	49	44	41	37
28	49	47	43	39	50	48	44	41	37	52	50	45	42	38
30	49	47	43	39	50	48	44	41	37	52	50	45	42	38
32	50	48	44	40	51	49	45	42	38	53	51	46	43	39
35	51	49	45	41	52	50	46	43	39	54	52	47	44	40
40	53	51	46	42	54	52	47	44	40	56	54	49	45	41
45	55	53	48	45	56	54	49	46	43	58	56	51	47	44
50	57	54	50	47	58	55	51	48	45	60	57	53	49	46
55	59	56	52	49	60	57	53	50	47	62	59	54	51	48
60	61	58	54	51	62	59	54	51	48		61	56	53	50

Send your message to this supplier

Message*

Email*

Phone or WhatsApp*

Name

Company

Please reply me within 24 hours.

Yes! I would like your verified suppliers matching service!

Send Now

Submission successful!

Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

Name: Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material
Brand: BUGAO
Price: 1 USD

Ask Latest Price

Watch Video

Product Detail

Brand Name :

BUGAO

Model Number :

608

Place Of Origin :

Ningbo, China

Certification :

ISO9001:2015

MOQ :

3000 Pcs

Price :

Negotiable

Contact Supplier

video

Ningbo Kent Bearing Co., Ltd

Verified Supplier

1 Years

zhejiang, ningbo

Since 2003

Business Type :

Manufacturer

Main Products :

6000 Series Bearing, Electric Motor Bearing, 6200 Series Bearing

Certification Level :

Verified Supplier

Discover similar products

video

Single Row Groove Ball Bearing 6005 2RS with Size 30x55x13mm

Contact Now
P5 P6 608 2RS Skateboard Bearing 8x22x7mm Bearing With Rubber Seal

Contact Now
608 Deep Groove Ball Bearing Chorme Steel Ball Bearings

Contact Now
10x26x8mm 6000ZZ High Speed Metal Shielded Ball Bearing ABEC-3

Contact Now
video

6000 Series Ball Bearing 609 6001 6004 for Garden tools

Contact Now
608-ZZ Skateboard Bearings Double Sealed Roller Skates Miniature Bearing

Contact Now
video

6002ZZ High Speed and High Precision Electric Tool Bearings

Contact Now
Double Sealed 6000 Series Bearing 12x28x8mm 6001ZZ Bearing High Speed

Contact Now
video

6001ZZ High Speed Silent Motor Bearings Factory Direct Supply ABEC-5

Contact Now
video

High temperature resistance 6000 Series Bearing 6001 2RS Bearing

Contact Now

Find Similar Products By Category:

Supplier Homepage Products 6000 Series Bearing

MachineU China Products Minerals & Metallurgy Alloy Steel Bearing Steel

Dimensional Diagram (608 Bearing Standard Sizes)

Key Advantages & Applications

Performance Benefits:

Typical Applications:

Applications:

Z4V4 Ball Bearings 608 Bearing ABEC 5 In Customized Stainless Steel Material

Ningbo Kent Bearing Co., Ltd

Single Row Groove Ball Bearing 6005 2RS with Size 30x55x13mm

P5 P6 608 2RS Skateboard Bearing 8x22x7mm Bearing With Rubber Seal

608 Deep Groove Ball Bearing Chorme Steel Ball Bearings

10x26x8mm 6000ZZ High Speed Metal Shielded Ball Bearing ABEC-3

6000 Series Ball Bearing 609 6001 6004 for Garden tools

608-ZZ Skateboard Bearings Double Sealed Roller Skates Miniature Bearing

6002ZZ High Speed and High Precision Electric Tool Bearings

Double Sealed 6000 Series Bearing 12x28x8mm 6001ZZ Bearing High Speed

6001ZZ High Speed Silent Motor Bearings Factory Direct Supply ABEC-5

High temperature resistance 6000 Series Bearing 6001 2RS Bearing

Find Similar Products By Category:
