5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
Specifications
Place of Origin :
CHINA
Brand Name :
OEM
MOQ :
Negotiable
Price :
Negotiation
Type :
PERC, Standard Solar Panel
Size :
1956*992*40mm
Panel Efficiency :
17%
Certificate :
CE, TUV TUV IEC, TUV IEC CE
Warranty :
25 years, 25 years
Solar Cell :
poly 156*156mm
Weight :
21Kgs
Front Glass :
Tempered Glass 3.2 mm
Frame :
Anodized Aluminium Alloy
Junction Box :
TUV Certificate IP65
Connector :
MC4 Connector
Name :
5BB poly solar cell 300w 310w 320w pv solar panel
Selling Units :
Single item
Single package size  :
196X100X6 cm
Single gross weight :
35.000 kg
Certification :
ISO9001, CE, SGS
Packaging Details :
Multiple packaging
Delivery Time :
10-15 working days
Payment Terms :
T/T, L/C, T/T, Western Union
Supply Ability :
10000PCS
Description

5BB Poly Solar Cells 300w 310w 320w PV Solar Panels

Product Description

Model JX310P JX315P JX320P JX325P JX330P
Rate Maximum Powe at STC 310W 315W 320W 325W 330W
Maximum Power Voltage(Vmp) 37.22V 37.33V 37.4V 37.6V 37.8V
Maximum Power Current (Imp) 8.33A 8.46A 8.56A 8.66A 8.74A
Open Circuit Voltage (Voc) 46.02V 46.1V 46.4V 46.7V 46.9V
Short Circuit Current (Isc) 8.71A 9.03A 9.05A 9.10A 9.14A
Module Efficiency 16.00% 16.19% 16.49% 16.75% 17.01%
Power Tolerance 0~+3% 0~+3% 0~+3% 0~+3% 0~+3%
STC Irradiance 1000w/m2,module temperature 25℃,air mass 1.5

Mechanical Parameters
Cell Type Poly-crystalline 156*156mm(6 inch)
No.of Cells 72(6×12)
Dimension 1956*992*40mm
Glass 3.2mm,high transmission,low iron,tempered glass
Junction Box IP65 & IP67 Rated
Output Cable Section size:4mm2,length:900mm
Frame anodized aluminum alloy
No.of Bypass Diodes 3&6
Connector MC4 compatible
Weight 22.5kgs

5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
