Specifications
Brand Name :
Xi'an Lvneng
Model Number :
4A Molecular Sieve
Certification :
ISO9001:2008
Place of Origin :
Shaanxi,China
MOQ :
10 Kilograms
Price :
Negotiable
Supply Ability :
50 Tons/ per Month
Delivery Time :
3-15 work days
Packaging Details :
1. Carton Drum/25KG 2. Carton Box/25KG; 3. Iron Drum/150KG
Payment Terms :
L/C, T/T
Size :
2.0-3.0mm;3.0-5.0mm,4.0-6.0mm
Shape :
granular strip
Color :
beige
Quality Management :
ISO9001
Stacking density g/ml :
0.66
Static adsorbed methanol %≥ :
15.0
Static adsorbed water %≥ :
22.0
Certificate :
SGS & REACH
Description

Molecular Sieve Desiccant Used For Removing Water From Air-Braking Systems

Overview

Heavy vehicles such as trucks and buses use air to power their brakes. Air must be kept as dry as possible to avoid any freezing in the circuit but also any corrosion of the metallic parts.


Molecular Sieve 4a with high crush strength, abrasion resistance is specifically designed for air actuated brake systems to dehydrate the compressed air and keep brake lines from freezing and corroding.

Molecular sieve 4a is specially designed for air brake system.

Molecular Sieve 4a Air Break Desiccant is used especially for desiccation of air-actuated braking systems in cars, trucks, train and ship. Molecular Sieve 4a possesses the high strength and H2O adsorption capacity, the low dust contamination and attrition resistance required withstanding high vibration.

Technical Index

Air Brake System Drying Molecular Sieve Typical Physical Properties
Items Unit 10*14 Mesh 8*12 Mesh
Bead Size mm 1.5-2.0 1.6-2.5
Bulk Density g/ml ≥ 0.70-0.80 0.70-0.80
Equilibrium Water Capacity @ 25 wt% 19.0-21.0 19.0-21.0
Heat of Adsorption BTU/lb of H2O 1800 1800
Crush Strength Point Contact N ≥ 35-70 50-100
Variation Coefficient - 0.3 0.3
Attrition Rate Dry wt% 0.1 0.1
Wet wt% 1.5 1.5
Size Qualification % 97 97
Package Moisture wt% 1.5 1.5
The interval value of the indexes above are on the basis of the different grade of Air Brake System Desiccant

Storage

The molecular sieve shall be stored at room temperature, in which the relative humidity does not exceed 90%, and be not exposed to air, and prevented against water, acids and alkalizes.

FAQ


1.Q: Could we send a free sample for reference?
A: Yes, of course. Don't be shy, go ahead asking for a sample :)
2.Q: What about the price and MOQ?
A: We promise the price we offered is the most competitive with top quality! we accept both large and small quantity order.
3.Q: What is the lead time?
A: With in7-20days after the receipt of payment or L/C.
4.Q: Payment term?
A: 100&TT in advance, 30% TT deposit before shipment balance against copy of B/L, L/C at sight.
5.Q: How to solve the quality problems after sales?
A: Take photos of the problems and send to us. After we confirm the problems, within three days, we will make a satisfying solution for you.
More information please contact us. It's our pleasure to solve the question for you.
