Specifications
Brand Name :
Xi'an Lvneng
Model Number :
Molecular Sieve XH-5 XH-7 XH-9 XH-11
Certification :
ISO9001:2008
Place of Origin :
Shaanxi,China
MOQ :
10 Kilograms
Price :
Negotiable
Supply Ability :
50 Tons/ per Month
Delivery Time :
3-15 work days
Packaging Details :
1. Carton Drum/25KG 2. Carton Box/25KG; 3. Iron Drum/150KG
Payment Terms :
L/C, T/T
Purity :
97%
Static adsorbed water :
18%
Stacking density :
0.75 g/ml
Size :
1.7-2.5 mm
Color :
Beige
Shape :
Granular,Pellet
Description

Molecular Sieve Desiccant XH In Dehydrating For Air Conditioners And Iceboxes

Products Introduction

Refrigeration in industrial, automotive, and household applications is based on the rapid expansion of a refrigerant (typically chloride or fluoride containing hydrocarbon). During the expansion step, the refrigeration fluid evaporates causing a significant drop in temperature.

During this step, it critical to avoid ice formation in the expansion valve to prevent blockage of the entire refrigeration system. Removing all residual moisture from the refrigerant is the most effective way to prevent ice formation.

Xi'an lvneng molecular sieves are especially suitable for removing even small traces of water vapor and are therefore ideal for such highly moisture-sensitive refrigeration applications.

Technical Index:

Refrigeration Drying Molecular Sieve Typical Physical Properties
Items Unit XH-5 XH-7 XH-9 XH-11
Bead Size mm 1.6-2.5 1.6-2.5 1.6-2.5 1.6-2.5
Equilibrium Water Capacity @ 25℃ wt% ≥ 20.5-21.5 17.0-18.0 16.5-17.5 16.0-17.0
Bulk Density g/ml ≥ 0.80-0.90 0.80-0.90 0.80-0.90 0.80-0.90
Crush Strength N ≥ 60-100 60-100 60-100 60-100
Attrition Rate Dry wt% ≤ 0.1 0.1 0.1 0.1
Humidity wt% ≤ 2.0 2.0 2.0 2.0
Package Moisture wt% ≤ 1.5 1.5 1.5 1.5
The interval value of the indexes above are on the basis of the different grade of Refrigeration Desiccant

Application:

When choosing refrigerant, special molecular sieve should come into the first consideration.

1. The XH-5 refrigerant desiccant molecular sieve is a basic type for refrigeration desiccant

2. The XH-7 refrigerant desiccant molecular sieve is suitable for refrigerant with stable chemical properties such as R-134a.

3. The XH-9 refrigerant desiccant molecular sieve is suitable for all refrigerants.

Attention:

· The product cannot be exposed in the open air and should be stored in dry condition with the air-proof package.
· The product should be regenerated after a certain period of adsorption.

· The appropriate regenerated temperature would be better below 350℃.
