Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Plastic Injection Mold P20 Prehardend Forged Steel Block
Specifications
Brand Name :
takford
Model Number :
P20/1.2311/3CR2MO
Place of Origin :
CHINA
MOQ :
1 pc
Price :
usd 0.8-1.5/kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 tons per month
Delivery Time :
5-10 days
Packaging Details :
According to The Demand of The Customer Inquire, Standard Seaworthy Package
Product name :
forged P20 steel block
Technique :
Forged prehardend
Surface treatment :
black or machined, Black Bright Mirror(mill Polishing HL Etc), black surface or mi
standard :
AISI, DIN, ASTM, GB, JIS
Application :
mold steel, tool stee, die steel, special steel
Shape :
plate, sheet, steel plate/flat bar/round bar, plate/sheet/ flat bar, ba
Delivery condition :
raw, According to The Demand of The Customer Inquire, Standard Seaworthy Package
Description

Forged produciton P20 steel block is a standard mold steel pre-hardened to 300HB.

Material properties
Standard prehardened steel designed for plastic mold industry.

For which tools
Plastic injection mould cores and cavities, extension dies for thermoplastics.

For which plastics
Thermoplastics (PE, PP, PS), thermosetting plastics, transparent melts.

Specification

Product Name

alloy steel/carbon steel/steel round bar
Length custom-made
Width custom-made
Thickness any size can custom-made
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year

Material

3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13

/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714

Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53

40Cr/5140/35CrMo/42CrMo/4140/1.7225

C45/C50/1045/1050/S50C/S45C/T10/T8

M2/1.338/SKH51

CUSTOM-MADE

Chemical composition

Grade C Si Mn Cr Mo P S
DIN 1.2311 0.35~0.45 0.20~0.40 1.30~1.60 1.80~2.10 0.15~0.25 ≤0.03 ≤0.03
AISI P20 0.28~0.4 0.2~0.8 0.6~1.0 1.4~2.0 0.3~0.55 ≤0.03 ≤0.03

Plastic Injection Mold P20 Prehardend Forged Steel BlockPlastic Injection Mold P20 Prehardend Forged Steel Block

Plastic Injection Mold P20 Prehardend Forged Steel BlockPlastic Injection Mold P20 Prehardend Forged Steel BlockPlastic Injection Mold P20 Prehardend Forged Steel Block
