1. Product Parameters

• Material: ADC12 aluminum alloy (GB/T 1173-2013), known for excellent castability, mechanical strength and corrosion resistance

• Size Range: from 20 × 20 mm up to 800 × 800 mm

• Weight Range: 3 g to 8 000 g per part

• Machinery: 220 ton to 1 200 ton high-pressure die-casting machines

• Surface Finishes: Polishing, sand-blasting, powder-coating, anodizing, electroplating

• Dimensional Tolerance: typically ± 0.01–0.05 mm (depending on geometry)

• Certifications: ISO 9001, CE (RoHS, REACH available upon request)

• Design Support: Free DFM review; accepts STEP, IGES, DWG, DXF

2. Key Selling Points

1. High-Pressure Precision
   Ensures dense, void-free castings with thin-wall capabilities, enabling lighter yet stronger components.

2. Complex Geometry & Fine Detail
   ADC12’s fluidity under high-pressure injection captures intricate features and sharp edges directly from the mold.

3. One-Stop OEM/ODM Service
   From mold-flow simulation, tooling and die casting to CNC machining, surface treatment and assembly—all streamlined under one roof.

4. Rapid Turnaround & Scalability
   Prototype samples in 7–10 days; mass production within 15–30 days, scalable from dozens to tens of thousands of pieces.

5. Durability & Environmental Resistance
   Excellent corrosion and wear resistance; ideal for harsh environments (–40 °C to +120 °C).

3. Future Trends

• Integrated Sensor Housings: As IoT proliferation continues, die-cast aluminum housings will increasingly incorporate sensor mounts and cable channels directly in the mold.

• Lightweight & Sustainable Alloys: Development of modified ADC12 variants with higher recycled content to meet circular-economy goals.

• Hybrid Manufacturing: Combining high-pressure die casting with 3D-printed inserts for rapid iteration of complex internal passages.

4. Application Scenarios

5. Frequently Asked Questions

Q1: What is the minimum order quantity?
A1: MOQ starts from 1 piece for prototypes; volume pricing applies from 100+ units.

Q2: Which CAD formats do you accept?
A2: STEP, IGES, DWG and DXF are preferred to accelerate mold design.

Q3: How do you guarantee dimensional accuracy?
A3: We perform first-piece CMM inspection, mold-flow analysis and in-process X-ray or ultrasonic testing.

Q4: Can you apply custom coatings and colors?
A4: Yes—powder coating in any RAL color, anodizing, electrophoretic painting, silk-screen and laser marking.

Q5: What are your lead times?
A5: Sample parts in 7–10 days; tooling and mass production in 15–30 days, depending on complexity and quantity.

Q6: Do you offer post-casting machining and assembly?
A6: Absolutely—CNC milling, drilling, tapping, grinding and full sub-assembly services are available.
