Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Muz Tech Original SIMcom A8200E-M2 Wireless Module with R16 5G SA/NSA Support PCIe USB3.1 Interfaces and Wide Operating Temperature Range
Specifications
Model Number :
A8200E-M2
Place of Origin :
Shanghai, China
Brand Name :
SIMcom
MOQ :
1
Communication Interface :
PCIe, USB
Operating Temperature :
-30℃ ~ +70℃
Form Factor :
M2
Supply Voltage :
3.135~4.4V
Sub-6G NSA Speed :
2.15Gbps(DL)/550Mbps(UL)
Sub-6G SA Speed :
4Gbps(DL)/1Gbps(UL)
LTE Speed :
300Mbps(DL)/50Mbps(UL)
HSPA+ Speed :
42Mbps(DL)/5.75Mbps(UL)
Protocol Support :
TCP/IP/IPV4/IPV6/Multi-PDP/FTP/FTPS/HTTP/HTTPS/MQTTS/DNS/SSL3.0
USB Driver Support :
Win7/Win8/Win10/Win11/Linux/Android
5G Support :
R16 5G SA/NSA
Multi-Band Support :
5G NR/LTE-FDD/LTE-TDD
USB Version :
USB3.1
GPIO Interface :
Yes
AT Command Compatibility :
A8200X series
Description
Product Description
A8200E-M2 is a Multi-Band 5G NR/LTE-FDD/LTE-TDD module which supports R16 5G SA/NSA.
With a rich protocols, it is integrated with interfaces such as PCIe, USB3.1, GPIO etc. This module provides applications with great flexibility and ability of integration.
A8200E-M2 adopts M2 form factor. AT commands of A8200E-M2 are compatible with A8200X series modules. This also minimizes costs for
customer and shortens time to market.
It is designed for applications that need huge data transmission in various wireless situations. Due to its high efficiency,
security and flexibility, this module suits various applications.
Package & Shipping
Shipping Cost (Take the US for example (DHL)
The specific cargo weight is calculated based on the product volume
QTY (pcs)
weight(kg)
shipping cost(usd)
1-50
0.5
22
50-100
1
28
101-150
1.5
35
151-200
2
45
If you need more information or have any demands pls contact me~

Company Profile
FAQ
1.Can you provide photo?
For routine order products or stock, photos can provide immediately . For some special or uncommon products, photes can be provided photos before delivery.

2.Can you guarantee products original?
Yes, we mainly provide original brand products. For new products, warranty is one year.

3.What’s your date code?
Newest. For old models, will specify the date code.

How to Pay with your visa & master card:
1. Please create a personal buyer account before you buy from alibaba
2. Write your email address , when place an order.
3. Go to your email and clik the link, " Send Initial Payment / Pay Balance " or “go to pay" ,
4. Then choose “+Add a new card to pay in USD($)"
5. Fill in the bank card information , "Confirm and Pay" , that charge from your card derectely, place an order successful
