Specifications
Brand Name :
JESH
Model Number :
SS1212HM
Certification :
CE
Place of Origin :
China
MOQ :
1Unit
Price :
Negotiation
Payment Terms :
T/T, L/C, D/P, D/A
Supply Ability :
4000 Units per month
Delivery Time :
45 days
Packaging Details :
Regular factory packing
Color :
Green
Working Height :
13.8m
Platform Height :
11.8m
width :
1.14m
Length :
2.48m
Capacity :
320KG
Max drive speed :
3.5km/h
Platform extendable :
0.9m
Height-rails unfolde :
2.59m
Ground clearance-stowed :
10cm
Capacity on extension :
100kg
Turning radius(inside/outside) :
0/2.1m
Tire :
40.5*12,7m
Battery :
24V/260Ah
Weight :
2898kg
Description

SS1212HM Sky Lift Platform Mobile Elevating Work Platform Capacity 320kg

Features:


1) Open type hydraulic system with anti-burst pipe protection
2) Emergency lower function assures platform operators can get down safely in case of emergency
3) Single lifting oil cylinder structure guarantees hydraulic pressure balance
4) Safety bar on the scissor part of the machine ensures operator safety during repair

Technical Parameters

Model SS1212HM
Dimentions Metric
Working Height 10.1m
Platform Height 8.1m
Platform Length 2.27m
Platform Length-Extended 3.17m
Platform Extension 0.9m
Platform Width 1.14m
Height-folded 1.82m
Wheelbase 1.87m
Min. Ground Clearance-stowed 10cm
Min. Ground Clearance-Raised 2cm
Productivity
Platform capacity 320kg
Drive Speed 3.5km/h
Gradeability 25%
Raise/Lower Speed 68/42sec
Turning Radius(Inside/outside) 0/2.1m
Tire 40.5x12.7cm
Power Electric
Engine Bettery 24V/225Ah

SS1212HM Sky Lift Platform Mobile Elevating Work Platform Capacity 320kg
