Specifications
Place of Origin :
China (Mainland)
Brand Name :
OEM/Visionmastercn
Model Number :
VK6
Price :
Negotiable
MOQ :
1 Piece/Pieces
Certification :
CE
Payment Terms :
T/T, Paypal, Western Union, MoneyGram, L/C, D/A, D/P,
Supply Ability :
5000sets/month
Delivery Time :
3-5 days for sample order; Bulk order varied from 5-60 days based on order quantity and material, prouction schedule etc.
Packaging Details :
In a box together with all standard accessories
Signal :
PAL / NTSC
Sensor :
CMOS
Technology :
Infrared
Monitoring Device :
PC , Mobile Phone
Color :
Black
Product name :
Wide Angle Lens Vehicle Dash Cam , Infrared Night Vision Rechargeable Dash Cam
Resolution :
1920*1080P
Keyword :
Dash camera
Description

Wide Angle Lens Vehicle Dash Cam , Infrared Night Vision Rechargeable Dash Cam

Item Parameter
OS Linux
Language Chinese/English/Others (can be customized)
Video Compression H.264 Compression Mode
OSD Overlays information such as date time and vehicle ID

GUI

Graphical User

Interface

Can connect to external LED screen. Setup system parameters with the remote

control.

Video Record System

Video Input

4 channel,2 channels built-in , 2 channels expansion; 080P AHD HD / SD / Mixed

Video Input
Video Output 1 composite video output
Preview Support 1/2/4 channels full screen preview
Resolution Support 1080P/720P/D1/CIF, MAX:4channels 1080P
Video Quality 0-7 levels, 0 is the highest level, 7 is the lowest level.

Video Standard

PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field;

CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional; HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional; D1: 800Kbps ~ 3Mbps, multi levels video quality optional; 720P : 1Mbps~4Mbps, multi levels video quality optional;

1080P: multi levels video quality optional;

Record Mode

The default setting is auto recording after power on. Timed recording, alarm

trigger recording and manual recording are supported.

Audio

 Audio Input 4CH ,2 channels built-in , 2 channels expansion
Audio Output 1 channel
Compression G.726 compression
Alarm Input 1CH level Alarm Input
Alarm Output 1CH level Signal Output
Communication Interface 1CH RS232 &1 channel RS485

Wireless transfer

Support Built-in 3G network, WCDMA,CDMA2000,TD-SCDMA compatible with

GPRS,EDGE; Support Built-in 4G network, TTD-LTE, FDD-LTE
Position Support Built GPS/BD Module,can make playback analysis of vehicle routing
G-Sensor Support G-sensor

Video Storage

 Storage Max support 2X256GB SD Card

Upgrade

Support USB flash disk updating,SD card upgrade , OTA remote upgrade

automatically

Wide Angle Lens Vehicle Dash Cam , Infrared Night Vision Rechargeable Dash Cam

Wide Angle Lens Vehicle Dash Cam , Infrared Night Vision Rechargeable Dash Cam

File Format H.264
File System Special Car system File System

USB

Support Two USB Port: 2.0 - Front panel supports USB port, support USB flash

disk upgrade to backup; hard disk box USB port, can back up video data

Video Playback

 Video Search Search video by Record Time/Record Type etc

Playback

 Max support 4CH Replay /Stop/Fast Forward/Fast Reverse at same time
Support x 2,x4,x8,x16. fast forward or fast backward play
Safety Management User/Admin 2 Levels Different Passwords , support screen lock
TTS Voice Broadcasting Support TTS voice broadcasting

Voltage & Power Consumpti on

 Power Management

Adaptive wide power input, with overload, undervoltage, short circuit, reverse connection and other protection functions; Support the timer switch machine,

delay shutdown function.
Voltage Input DC:+8V ~ +36V

Voltage Output

12V @1.2A 4 channels,with IR

12V @0.9A 2 channels,with IR

Power-off

Protection

UPS Technology,All video information can be saved automatically when the

power is cut off, and make sure that all the files can not be damaged.

Power

Consumption

 Normal Working ＜10W, Standby state <0.5W
Working Environme nt Temperature -20℃ to +70℃
Humidity 20% to 80%
Heater device Build-In Hard disk Heater(Temperature Sensor)

others

 Size 125mm*130mm*150mm
Net Weight 0.5Kg

***** Above parameters any changes,please refer to actual product *****
