100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
100W 200-300MHz Anti drone jammer module with customized frequency power amplifier module for FPV drones
Specifications
Brand Name :
Sacontelecom
Model Number :
SA-PA200-100
Certification :
ISO9001, CE
Place of Origin :
China
MOQ :
5pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,Paypal
Supply Ability :
5000pcs per Month
Delivery Time :
1-15 days
Packaging Details :
170*74*21.5(26.5) mm (Without Connector)
Product Name :
Frequency Range Anti-Fpv Drone Module
Frequency :
200-300mhz
Output Power :
50dBm, 100w
Working Current :
10 a±1.0
Size :
170*74*21.5(26.5) mm (Without Connector)
Weight :
0.45± 0.1kg
Description
100W Anti-Drone Jammer Module for 200-300MHz Customized Power Amplifier Module
Product Overview

Sacontelecom specializes in manufacturing various anti-drone jammer power amplifier modules, including FPV drone jammer modules. We offer customized solutions across multiple frequency ranges and power outputs to meet your specific requirements.

Available Frequency Ranges

We provide modules for frequencies including: 100-200MHz, 200-300MHz, 300-400MHz, 400-500MHz, 500-600MHz, 600-700MHz, 700-800MHz, 800-900MHz, 900-1000MHz, and 1G-1.1GHz. Popular customized frequencies include 433MHz, 900MHz, 1.2GHz, 1.5GHz, 1.4GHz, GPS, 5.2GHz, 5.5GHz, and 5.8GHz.

Power Options

Available power outputs: 10W, 20W, 30W, 50W, and 100W. All specifications can be customized to your specific needs.

Key Features
  • Frequency: 200-300MHz (customizable)
  • Power: 100W (customizable)
  • Fast delivery available
  • Samples available for testing
  • OEM and ODM services supported
Technical Specifications
Parameter Specification
Working Frequency 200-300MHz
Output Power 100W (50dBm)
Connector Type Female SMA / N Type
Signal Source VCO
Working Current 10A ±1.0
VSWR ≤1.5
Working Voltage DC 24-32V
Weight 0.45 ± 0.1kg
Dimensions 170 × 74 × 21.5(26.5) mm (Without Connector)
Humidity 30%-95%
Operating Temperature -20ºC to 80ºC

We can customize frequencies to meet your specific requirements.
