Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry
Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry
Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry
Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry
Specifications
Brand Name :
JN
Model Number :
EP800
Certification :
CE ISO
Place of Origin :
Hebei, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
120000 Meter/Meters per Month
Delivery Time :
7 Days
Packaging Details :
Standard export package or according to your demands
Color :
Black
Name :
EP 800 4 Ply Mpa 18
Edge :
Molded Edge or Cut Edge
Application :
Metallurgy cement coal port chemical
Tensile Strength :
6mpa-25mpa
Width :
400mm-2200mm
Fabric :
CC, EP, NN
Thickness :
4-50mm
Description

Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry

Conveyor belt type include :

· Anti-split conveyor belts

· Anti-abrasion conveyor belts

· Common conveyor belts

· Acid-alkali resistant conveyor belts

· Heat-resistant conveyor belts

· Cold -resistant conveyor belts

Conveyor belt feature:

· Excellent elasticity

· Anti-impact

· High-adhesion

· Good flexibility

· Trough ability

· Better stability of size

· Resistance to water

· Heat resistance in comparison to NN belt

Conveyor belt Specification and technical parameter:

Fabric type Fabric structure Fabric type Fabric thickness Cover rubber thickness Width Length
warp weft Upper Lower
EP EP EP EP-100 0.75 1.5-8 0-4.5 400-2500 <=300
EP-150 0.8
EP-200 0.90 500-2500
EP-250 1.15
EP-300 1.25
EP-400 1.45 800-2500
EP-500 1.55

Fabric type Fabric structure Fabric type Fabric thickness Cover rubber thickness Width Length
warp weft Upper Lower
NN NN NN NN-100 0.75 1.5-8 0-4.5 400-2500 <=300
NN-150 0.8
NN-200 0.9 500-2500
NN-250 1.15
NN-300 1.25
NN-400 1.45 800-2500
NN-500 1.55

We could offer belt with cover grade in accordance to International standard such as DIN 22102, RMA, AS 1332, SABS 1173/2000, IS 1891, BS 490, JIS K 6322, etc.

Standards Cover Rubber Adhesion
Tensile Strength Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply
DIN 22102 Mpa % mm3 N/mm
(≤1.5mm)		 N/mm
(>1.5mm)		 N/mm
DIN 22102-Z 15 350 250 3.5 4.5 5
DIN 22102-W 18 400 90 3.5 4.5 5
DIN 22102-Y 20 400 150 3.5 4.5 5
DIN 22102-X 25 450 120 3.5 4.5 5

Standards Cover Rubber Adhesion
Tensile StrengTD Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply
AS 1332 Mpa % mm3 N/mm
(≤1.9mm)		 N/mm
(>1.9mm)		 N/mm
AS 1332-N17 17 400 200 4 4.8 6
AS 1332-M24 24 450 125 4 4.8 6

Heavy Duty Black EP NN CC Rubber Conveyor Belts For Mining Coal Industry
