Specifications
Application :
Loading, Warehouse, Logistic, 3D, Manufacture
Certification :
ISO
After-sales Service :
One Year
Docking Height :
610 mm (Standard)
Operating Speed(Full Load) :
0.6 M/S
Specification :
3500*2200*650 mm (Customizable)
Trademark :
Wellwit
Payload :
5000 Kg
Navigation :
Lidar Slam
Running Mode :
Omnidirectional Motion
MOQ :
1 Piece
Battery Type :
Lithium Iron Phosphate Battery
Charging Time :
<2.5 H
Charging Way :
Automatic and Manual Charging
Battery Life :
≥1500 Cycles
Battery Endurance :
≥6 H
Warranty :
One Year
Transport Package :
Wooden Box/Un Cardboard Box
Origin :
Shenzhen
Model NO. :
W5000DS
Emergency Stop Switch :
Support, Four in Total
Communication Mode :
WiFi
Condition :
New
Description
Mobile Robot Automated Warehouse Logistics Industrial Laser Agv RoboticsMobile Robot Automated Warehouse Logistics Industrial Laser Agv Robotics
Basic Specification Technical parameters Parameter Description
Model WR5000DS
Mass <5000 kg
Payload 5000 kg
Docking height 610 mm (Standard)
Dimension (L * w * h) 3500*2200*650 mm (Customizable)
Navigation LiDAR SLAM
Operating Performance Motion mode Forward/ backward/ rotation/ omnidirectional motion
Driving mode Double steering wheel drive
Operating speed(No load) 0.8 m/s
Operating speed(Full load) 0.6 m/s
Positioning accuracy  ±10 mm
Visual camera Second positioning: ±5 mm
Battery Performance Battery type Lithium iron phosphate battery     DC48V
Battery capacity 60 Ah
Battery life ≥1500 cycles
Endurance ≥6 h
Charging time ≤2.5 h
Charging way Automatic/ manual charging


Safety Protection		 Obstacle avoidance way Lidar obstacle avoidance + contact anti-collision strip
Emergency stop switch Support, four in total.
Communication mode WiFi
Audible and visual alarm Support
Debug interface Open interface
Environmental requirements Indoor,
Temperature: 0ºC ~ 50ºC(AGV can be used under the temperature),
Relative Humidity: 5%-95% (no condensation).)

Mobile Robot Automated Warehouse Logistics Industrial Laser Agv RoboticsMobile Robot Automated Warehouse Logistics Industrial Laser Agv Robotics
Mobile Robot Automated Warehouse Logistics Industrial Laser Agv RoboticsShenzhen WellWit Robotics Co., Ltd was established in Shenzhen in March 2015, our company focuses on research and development of mobile robot. The R&D team consists of members who experienced in field of robot, embedded hardware, software, algorithms, artificial intelligence, etc.
Currently, products for sale including moving robot, sorting robot, Auto-forklift, etc. Navigation method we provide including QR code navigation, LiDAR SLAM navigation, Visual SLAM Navigation, RTK navigation.
We focus on providing custom logistic robots for the integrators who focus on Intelligent Logistics and Intelligent Factory, and provide AGV&AMR with ODM/OEM service for global clients.
