Specifications
Brand Name :
SPR-ing
Model Number :
SP036020
Place of Origin :
Shenzhen
MOQ :
1
Price :
200-800USD
Payment Terms :
L/C,T/T
Supply Ability :
1000/month
Delivery Time :
1 week
Packaging Details :
Carton
Rotating Speed :
0~3000 RPM
Design loop :
20
Working Life :
10 million~100 million circle
Dynamic Resistance Change :
≤10mΩ
Working Temperature :
-40℃ to 60℃
Insulation Resistance :
200MΩ/250V/DC
Maximum Current :
1A
Shell Material :
Alluminum alloy/304 stainless steel/316L stainless steel
Description

Featuring dynamic resistance variation ≤ 10 mΩ, the SP036020 slip ring ensures low-noise and high-stability signal transmission, even during continuous high-speed operation.

It supports 250VDC / 3A per channel and offers high insulation resistance (200 MΩ @ 250VDC), making it suitable for both power and sensitive signal transmission in high-speed applications.

Technical parameters

Electrical specifications

Design loop

20

Insulation resistance

200MΩ/250V/DC

Rated voltage/current

250VDC/3A

Dielectric strength

≥250VAC/50Hz/60s

Dynamic resistance change value

≤10mΩ

Wire length

Standard 300 ± 20mm (optional)

Mechanical specifications

Rated speed

0~3000 rpm

Working life

10 million~100 million circle

Operating temperature

-45℃ ~ 60℃

Contact material

Gold-gold

Shell material

Alluminum alloy/304 stainless steel/316L stainless steel

Maximum starting torque

3.5N.cm

IP grade

IP51


Outline Drawing

Multi Mode Fiber Optic Rotary Joint Optical Slip Ring for ROV


Technical advantages:

ü Slipring's core technology - friction pair technology: gold metal contact technology, ensuring an ultra long service life.

ü Integrated casting process: Ensure the concentricity between the ring groove and the bearing is ≤ 0.01mm.

ü Mirror processing technology: Ensure that the smoothness of the slip ring contact surface can reach Ra0.02, making the contact more reliable.

ü Precision component manufacturing process: dimensional tolerance<0.01mm, axial displacement<0.01mm, high precision, and more stable performance.

ü Advanced brush wire modulation technology: Nearly zero pressure brush design and debugging process, extending the life of the slip ring by 1/3.

ü High speed, this slip ring can reach a maximum speed of 8000 revolutions per minute (with cooling system).

ü Long lifespan, with a maximum lifespan of up to 100 million revolutions per minute.
