Specifications
Brand Name :
SPR-ing
Model Number :
SP016044
Place of Origin :
Shenzhen
MOQ :
1
Price :
200-800USD
Payment Terms :
L/C,T/T
Supply Ability :
1000/month
Delivery Time :
1 week
Packaging Details :
Carton
Rotating Speed :
0-100 rpm
Design loop :
≤44
Working Life :
5 million rpm
Dynamic Resistance Change :
≤20mΩ
Working Temperature :
-55℃ ~ 85℃
Maximum Current :
1A
Shell Material :
Stainless steel
Contact material :
Gold-gold
Description
Versatile Conductive Slip Ring Designed for in Rotating Electrical Systems Providing Consistent Signal and Power Transmission

Precision-engineered conductive slip ring designed to ensure stable electrical performance in continuous rotation applications. Built for harsh environments with corrosion-resistant stainless steel construction and gold alloy contacts that resist oxidation, sulfurization, and chemical exposure.

Technical Advantages

  • Gold-gold contact provides high conductivity, excellent thermal conductivity, low temperature coefficient of resistance, with resistance to sulfurization, oxidation, and corrosive gases
  • Superior hardness and wear resistance with excellent resistance to welding, arc corrosion, and burns
  • Integrated casting process ensures concentricity between ring groove and bearing ≤ 0.01mm
  • Mirror processing technology achieves contact surface smoothness of Ra0.02 for more reliable contact
  • Precision component manufacturing with dimensional tolerance <0.01mm for high precision and stable contact
  • Near-zero pressure electric brush design extends slip ring life by 1/3
  • Compact size and structure meets space constraints in various applications
  • Integral stainless steel metal construction suitable for extremely harsh environments
Technical Specifications
Electrical Specifications
Design Loop ≤44
Insulation Resistance 250MΩ/250V/DC
Rated Voltage/Current 48VDC /1A
Dielectric Strength >200VAC/50Hz/60s
Dynamic Resistance Change Value ≤20mΩ
Mechanical Specifications
Rated Speed 0-100 rpm
Working Life 5 million rpm
Operating Temperature -55℃ ~ 85℃
Contact Material Gold-gold
Shell Material Stainless steel
Maximum Starting Torque 0.4 N.cm
Weight <20g (not include wire)
IP Grade IP51~IP68 optional
Outline Drawing
