3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
Specifications
Brand Name :
WOOSIM
Model Number :
PORTI-P340/P440
Certification :
CE,FCC,ROHS
Place of Origin :
CHINA
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C,T/T
Supply Ability :
10000PCS/MONTH
Delivery Time :
5-8 work days
Packaging Details :
carton, 100pcs/ carton
Size :
small 58mm thermal
Printing width :
72mm or 102mm
Paper width :
80mm or 110mm
Printing method :
Directly thermal
Interface :
RS232C, Parallel
Resolution :
203 dpi
Speed :
50mm/s
Drive :
support
Life :
50km
Input :
5v, 9v, 12-24v
Description

woosim 3 inches small size embedded thermal mount ticket panel printer

PORTI-P340/P440

- Ultra small size rack mount printer

- High speed (40mm/sec, MAX)

- High resolution (203dpi, 8dots/mm)

- UART(RS-232C or TTL).

Item Specification
Printing method Direct thermal line printing
Characters per line 64cpl (MAX)
Character size Eng. : 9x24dots, 12x24dots
Kor. : 16x24dots [24x24dots]
Optional Characters Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish, Greek, Japanese, Persian, Latin9 and Others upon request.
Resolution 203dpi, 8dots/mm
Print width 3-inch (72mm, 576dots)
Printing speed 40mm/sec(MAX)
Dimensions 110 x 77.7 x 49.1mm
Weight 177g
Interface UART (RS-232C or TTL)
Paper supplied Thermal roll paper (80mm wide, 38ø),
Paper thickness : 60±5㎛
Barcode supported 1-dimension : Code128, Code39, I2/5, Code93, UPC-A, UPC-E,
EAN8, EAN13, CODABAR
2-dimension : PDF417, QR Code, DATA Matrix, Micro PDF417,
Truncated PDF417
Driver Microsoft Windows XP / VISTA / 7
Windows CE, Linux, Android, Blackberry
H/W spec MCU: 32 bits RISC, FLASH: 4M bytes, RAM: 8M bytes
Receive buffer size 1M bytes
Input Power 9VDC, Standby 60mA and Max3.0A
Operating temperature -10°C~50°C
Storage temperature -10°C~70°C
MCBF(Mean Cycle Between failure) Mechanical 37,000,000 lines
Head Approximately 50 Km

3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution

3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution

3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution

3 Inches Ticket Panel Embedded Thermal Printer Rack Mount High Resolution
